VDO 180-035-008G - Cockpit International Oil Temperature Mechanical 150°C 52mm

Article VDO.180035008G

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The VDO 180-035-008G is a 52mm mechanical oil temperature gauge with a range of +40°C to +150°C, designed for accurate temperature measurement. It features a dry sensor with an M10 x 1 connection and measures 67.5mm in depth. The gauge operates with 12 or 24 volts for illumination and connects via an AMP male blade connector. It does not include flushmount options but can be securely mounted with a bracket. Accuracy specifics are not provided by VDO.

Description
Ask a Question

VDO 180-035-008G - Cockpit International Oil Temperature Mechanical 150°C 52mm

The VDO 180-035-008G is a precision-engineered mechanical oil temperature gauge designed to provide accurate readings for your vehicle's oil temperature. This gauge features a 52mm (2 1/16 inch) installation diameter and an outside diameter of 59.25mm (2 1/3 inch), with a depth of 67.5mm. It is equipped with a dry sensor that measures temperatures ranging from +40°C to +150°C, ensuring reliable performance under various conditions.

The sensor's connection is made through an M10 x 1 thread with a length of 2.600mm. The gauge does not include a flushmount option and has no specified locking height with a Spinlock nut, but it can be securely installed using a bracket with a locking height range of 0.5mm to 8mm. For illumination, the gauge is designed to connect with an AMP male blade connector (6.3 x 0.8mm, 2x), operating at 12 volts with a 2-watt current consumption or optionally at 24 volts with the same power requirements. Accuracy details are not specified by VDO, but the gauge is built to meet high standards of reliability and functionality.
