The BEP 907-DCSM is a 12V DC circuit breaker panel with an integrated digital meter, designed to manage up to 48 single pole protected circuits in one compact distribution unit. Breaker configuration includes 12x 5A, 15x 10A, 15x 15A, 3x 20A, 1x 25A, and 2x 30A, with a maximum amperage of 160A per bus. Dimensions: 15" x 18.25" x 2.5" (380 x 463 x 64 mm). The panel includes 2 x 24-way negative buses and label sheets (1–5) for circuit identification.
- Description
- Ask a Question
-
BEP 907-DCSM – DC Circuit Breaker Panel with Digital Meter, 48 Loads, 12V, Single Pole
The BEP 907-DCSM is a high-capacity DC circuit breaker panel designed for structured power distribution and circuit protection in 12V DC systems. It includes an integrated digital meter and provides protection for 48 individual load circuits using single pole circuit breakers.
Key Specifications
- Part number: 907-DCSM
- Nominal voltage: 12V DC
- Meter: Digital
- Total positions: 48 loads
- Circuit breaker type: Single pole
- Maximum amperage: 160A per bus
Circuit Breaker Configuration (Single Pole)
- 12 × 5A
- 15 × 10A
- 15 × 15A
- 3 × 20A
- 1 × 25A
- 2 × 30A
Dimensions
- H × W × Depth: 15" × 18.25" × 2.5"
- H × W × Depth (mm): 380 × 463 × 64 mm
Negative Bus & Labeling
- Negative bus: 2 × 24-way
- Label sheets included: 1–5
Application
With 48 protected circuits, a digital meter, and a compact panel footprint, the BEP 907-DCSM is suitable for larger 12V DC installations where clean circuit organization, reliable protection, and centralized distribution are required.
-
