BEP 906-DCSM – DC Circuit Breaker Panel with Digital Meter, 32 Loads, 12V, 7x5A + 11x10A + 11x15A + 1x20A + 1x25A + 1x30A

ID 1330824

$ 3,271.36

1-2 weeks delivery time

- +

Add to cart

The BEP 906-DCSM is a 12V DC circuit breaker panel with an integrated digital meter, designed to manage and protect up to 32 single pole load circuits. Breaker layout includes 7x 5A, 11x 10A, 11x 15A, 1x 20A, 1x 25A, and 1x 30A, supporting structured distribution across mixed DC loads. The panel provides 160A per bus maximum amperage, includes a 24-way negative bus, and comes in a horizontal format with compact installation dimensions of 295 x 463 x 65 mm.

Description
Ask a Question

BEP 906-DCSM – DC Circuit Breaker Panel with Digital Meter, 32 Loads, 12V

The BEP 906-DCSM is a 12V DC circuit breaker panel with an integrated digital meter, designed for organized circuit distribution and protection across 32 single pole load positions. It is suited for DC installations requiring multiple protected circuits, a centralized layout, and clear monitoring directly on the panel.

Main Specifications
- Part number: 906-DCSM
- System voltage: 12V DC
- Total positions: 32 loads
- Circuit breaker type: Single pole
- Meter type: Digital
- Maximum amperage: 160A per bus
- Negative bus: 24-way
- Dimensions (H x W x D): 295 x 463 x 65 mm
Circuit Breaker Configuration

Breaker Rating Quantity

5A 7

10A 11

15A 11

20A 1

25A 1

30A 1

Included Label Sheet
- Label sheet: 1–4
Overview

With a 32-load layout, integrated digital monitoring, and a 24-way negative bus, the BEP 906-DCSM provides a structured solution for multi-circuit DC distribution where organized protection and clear circuit management are required.
