ID
1317225
$ 173.23
1-2 weeks delivery time
-
+
The Wika Bourdon Tube Pressure Gauge with a 316Ti stainless steel measuring system and a 63 mm stainless steel case features a bottom connection with back flange and measures pressure from 0 to 6 bar. It is suitable for non-aggressive gases and liquids in pneumatics, hydraulics, shipping, chemical, and food industries, and complies with accuracy class 1.6 per DIN 16005.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 63mm Bottom Connection With Back Flange 1/4'' 0-6 Bar
Equipped with a back flange for flexible mounting options, this pressure gauge is ideal for measuring non-aggressive gases and liquids in the pneumatics, hydraulics, shipping, chemical, and food industries. It features a 316Ti stainless steel measuring system and maintains accuracy class 1.6 per DIN 16005.
- Case: Ø 63 mm, with bottom connection and back flange
- Case material: Stainless steel 304
- Measuring system: 316Ti stainless steel
- Dial: White with black lettering
- Pointer: Black
- Window: Safety glass/polycarbonate
- Case fill: Dry
- Dimensions: As per DIN16064
- Product code: 40.26.202
- Connection: 1/4" BSP bottom connection with back flange
- Measuring range: 0 - 6 bar
-
