ID
1317232
$ 173.23
1-2 weeks delivery time
-
+
The Wika Bourdon Tube Pressure Gauge with a 316Ti stainless steel measuring system and a 63 mm stainless steel case includes a bottom connection with back flange and measures pressure from -1 to +5 bar. It is designed for industrial applications in pneumatics, hydraulics, shipping, chemical, and food sectors, meeting accuracy class 1.6.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 63mm Bottom Connection With Back Flange 1/4'' -1+5 Bar
Built for a range of industrial applications, this pressure gauge is ideal for monitoring non-aggressive gases and liquids in pneumatics, hydraulics, shipping, chemical, and food sectors. It is equipped with a 316Ti stainless steel measuring system and features a back flange for flexible installation. Fulfills accuracy class 1.6 according to DIN 16005.
- Case: Ø 63 mm, with bottom connection and back flange
- Case material: Stainless steel 304
- Measuring system: 316Ti stainless steel
- Dial: White with black lettering
- Pointer: Black
- Window: Safety glass/polycarbonate
- Case fill: Dry
- Dimensions: As per DIN16064
- Product code: 40.26.305
- Connection: 1/4" BSP bottom connection with back flange
- Measuring range: -1 + 5 bar
-
