A4 stainless steel extra wide flat washers feature an outer diameter four times the nominal hole diameter, providing an enlarged bearing surface for fastening applications. Available in eight sizes from 4×16 mm to 16×64 mm, these corrosion-resistant washers are suitable for marine, outdoor, construction and industrial applications. The range includes hole diameters of 4, 5, 6, 8, 10, 12, 14 and 16 mm, with corresponding outer diameters of 16, 20, 24, 32, 40, 48, 56 and 64 mm. Each size is supplied in packs of 10 to 40 pieces depending on the selected variant.
- Description
- Ask a Question
-
A4 Stainless Steel Extra Wide Flat Washers – 4× Hole Diameter, 4–16 mm
A4 stainless steel extra wide flat washers feature an outer diameter four times the nominal hole diameter. Their enlarged bearing surface is designed to distribute fastening loads over a wider area and provide support around bolts and other threaded fasteners.
These washers are made from corrosion-resistant A4 stainless steel and are suitable for marine, outdoor, construction and industrial fastening applications. The range includes eight sizes, from 4×16 mm to 16×64 mm, with package quantities depending on the selected dimensions.
Technical Specifications
Product Type Extra Wide Flat Washer Material A4 Stainless Steel Diameter Ratio Outer diameter = 4× nominal hole diameter Hole Diameters 4, 5, 6, 8, 10, 12, 14, 16 mm Outer Diameters 16, 20, 24, 32, 40, 48, 56, 64 mm Package Quantities 10, 20, 25 or 40 pcs Applications Marine, outdoor and general fastening
Features and Applications
- Extra wide flat washer design with a 4:1 outer-to-hole diameter ratio.
- A4 stainless steel construction for corrosion resistance.
- Provides a larger bearing surface for load distribution.
- Suitable for marine, outdoor and industrial environments.
- Available in eight sizes with nominal hole diameters from 4 to 16 mm.
- Supplied in packs of 10 to 40 pieces depending on size.
Available Sizes and Part Numbers
Hole Diameter Outer Diameter Quantity FNI Part No. 4 mm 16 mm 40 pcs 7700070 5 mm 20 mm 25 pcs 7700071 6 mm 24 mm 25 pcs 7700072 8 mm 32 mm 20 pcs 7700073 10 mm 40 mm 20 pcs 7700074 12 mm 48 mm 20 pcs 7700075 14 mm 56 mm 10 pcs 7700076 16 mm 64 mm 10 pcs 7700077 -
