ID
1396072
$ 566.15
1-2 weeks delivery time
Diameter, mm:
- 7
- 9
Length, m:
- 100 m
The PARAFIL cable is made from continuous Terylene yarn with a white alkathene outer sheath and is designed for guardrail applications. It is available in Ø7 mm and Ø9 mm diameters, both supplied in 100 m coils. The Ø7 mm version has a breaking load of 510 kg and weighs 37 g/m, while the Ø9 mm version has a breaking load of 1015 kg and weighs 55 g/m. The cable combines strength close to steel with lower weight, high electrical insulation and maintenance-free construction.
- Description
- Ask a Question
-
PARAFIL Guardrail Cable with White Alkathene Sheath – Ø7 / Ø9 mm, 100 m Coil
The PARAFIL cable is composed of continuous Terylene yarn covered with a white alkathene sheath. It is intended for guardrail installations and provides strength close to that of steel while remaining lighter, highly insulating and maintenance-free.
Two cable diameters are available: Ø7 mm and Ø9 mm. Both versions are supplied in 100 m coils, with different breaking loads and weights per metre.
Key Features
- Continuous Terylene yarn construction
- White alkathene outer sheath
- Strength close to steel
- Lightweight construction
- Highly insulating
- Maintenance-free
- Ideal for guardrails
- Supplied in 100 m coils
Available Versions
Code Diameter Breaking Load Weight Coil Length 03.182.07 Ø7 mm 510 kg 37 g/m 100 m 03.182.09 Ø9 mm 1015 kg 55 g/m 100 m
Technical Specifications
Core Material Continuous Terylene yarn Outer Sheath White alkathene Available Diameters Ø7 mm / Ø9 mm Coil Length 100 m Application Guardrails -
