ID
1385004
$ 4.27
1-2 weeks delivery time
Diameter, mm:
- 6
- 8
- 10
- 12
The Plastimo Grade 70 Omega Shackles are heavy-duty forged connectors designed specifically for marine anchor chains. Manufactured to DIN EN 13889 G50 specifications with RR C271 certification, these omega shackles provide high breaking strength while maintaining a compact profile for secure chain connections. Available for 6 mm, 8 mm, 10 mm, and 12 mm chains, they are suitable for demanding anchoring, mooring, lifting, and industrial applications.
- Description
- Ask a Question
-
Plastimo Grade 70 Omega Shackles for Chain
The Plastimo Grade 70 Omega Shackles are engineered for reliable connection of anchor chains and heavy-duty marine hardware. Their forged Grade 70 construction delivers exceptional strength while maintaining a compact omega profile that fits chain applications efficiently.
Designed in accordance with DIN EN 13889 G50 and RR C271 certification requirements, these shackles provide dependable performance for demanding marine and industrial environments. Each size is optimized for a specific chain diameter, ensuring secure installation and maximum load capacity.
Key Features
- Forged Grade 70 omega shackle
- Designed for marine anchor chains
- Certified to DIN EN 13889 G50
- RR C271 certified
- High breaking strength
- Compact omega design for secure chain connection
- Suitable for anchoring, mooring and lifting applications
- Available for 6 mm, 8 mm, 10 mm and 12 mm chains
Available Variants
Plastimo SKU Suitable Chain Internal Dimensions (H × W) Break Load Weight 67416 Ø 6 mm 48 × 28 mm 4033 kg 0.120 kg 67417 Ø 8 mm 49 × 28 mm 7170 kg 0.250 kg 67418 Ø 10 mm 60 × 35 mm 11200 kg 0.400 kg 67419 Ø 12 mm 72 × 39 mm 16130 kg 0.700 kg
Technical Specifications
Product Type Omega Shackle Grade Grade 70 Certification DIN EN 13889 G50 / RR C271 Suitable Chain Sizes 6 mm, 8 mm, 10 mm, 12 mm Applications Anchor chains, mooring systems, lifting and marine rigging
Applications
- Anchor chain connections
- Marine anchoring systems
- Mooring equipment
- Commercial and recreational vessels
- Heavy-duty lifting applications
- Industrial rigging systems
-
