$ 1,564.98
1-2 weeks delivery time
-
+
The Webasto 602431B000003 Isotemp Basic 24 single-coil water heater combines a brushed stainless steel cover with an innovative internal design to maximize capacity through optimized placement of the engine water heat exchanger and the immersion heater. A long corrugated coil supports high heat exchange efficiency, while ultra-thick insulation helps minimize temperature loss. It includes a 7.0 bar (100 psi) safety valve, a simple winter drain, and a plug-and-play immersion heating element designed to heat water at the bottom of the tank. Volume is 24 litres with dimensions 470 mm x 395 mm and weight 12.5 kg.
- Description
- Ask a Question
-
Webasto 602431B000003 Isotemp Basic 24 Single-Coil Water Heater
The Webasto Isotemp Basic 24 is a 24-litre water heater with a single coil, built around stainless steel construction and an internal layout designed to achieve high capacity. It uses an engine water heat exchanger arrangement and an immersion heater to support efficient water heating in a compact form factor.
Application
- Water heating via an engine water heat exchanger and an immersion heater
- Designed for installation flexibility, including bulkhead mounting
Technical Specifications
Part Number 602431B000003 Volume 24 litres Dimensions 470 mm x 395 mm Weight 12.5 kg Safety Valve Rating 7.0 bar / 100 psi
Product Details
- Model line: Isotemp
- Version: Basic 24
- Coil configuration: Single coil
- Cover: Brushed stainless steel cover
- Water tank material: Stainless steel
- External cylinder material: Stainless steel
- Fixing feet: Stainless steel
- Historical product codes:
- 60.2431.00.00.03
- 60.2431.00.0003
- 602431000003
Features
- Extra-long corrugated coil for high heat exchange efficiency
- Simple winter drain
- Ultra-thick insulation for low temperature loss
- Plug-and-play immersion heating element designed to heat water at the bottom of the tank
- Thermostat mixing valve available as an option
- Robust design
- Adjustable mounting for easier installation, including on a bulkhead
-
