The Jabsco AQS2-13 diaphragm-actuated pressure switch delivers dependable pressure control with a 10 to 65 PSI adjustment range and a 220 PSI maximum pressure rating. Its 2-pole configuration and 0.25 inch NPSF connection support flexible installation, while the NEMA 1 rating with UL Listing and CSA Certification helps meet recognized safety and quality standards. The switch supports multiple horsepower ratings for single-phase and three-phase applications across several voltage options.
- Description
- Ask a Question
-
Jabsco AQS2-13 Diaphragm-Actuated Pressure Switch
The Jabsco AQS2-13 is a pressure switch built to manage system pressure reliably across a wide range of applications. Using a diaphragm actuator, it supports consistent switching performance and is suited to installations where recognized electrical ratings and certifications are required.
Application
- Pressure management for various applications
- Single-phase applications
- Three-phase applications
Technical Specifications
Actuation Type Diaphragm actuator Pressure Range 10 to 65 PSI Maximum Pressure 220 PSI Control Range (As Stated) 40 to 60 PSI Poles 2-pole Connection 0.25 inch NPSF Enclosure Rating NEMA 1 Certifications UL Listed, CSA Certified
Product Details
Single-Phase Motor Rating 1.5 HP at 115 VAC; 2 HP at 230 VAC Three-Phase Motor Rating 2 HP at 115 VAC; 3 HP at 230 VAC; 1 HP at 460 VAC and 575 VAC
Features
- Diaphragm actuator supports precise pressure switching
- Wide adjustment range of 10 to 65 PSI with a 220 PSI maximum pressure rating
- 2-pole configuration for compatible electrical setups
- 0.25 inch NPSF connection for installation versatility
- NEMA 1, UL Listed, and CSA Certified for recognized compliance and safety expectations
-
