ID
1331259
$ 322.28
1-2 weeks delivery time
-
+
The Jabsco 18590-2094 macerator pump is a 24V waste-handling unit built for marine waste management, combining grinding capability with run-dry protection and a sealed motor design to support reliable onboard discharge. It is specified as self-priming up to 0.6 m vertical lift and is also listed as self-priming up to 1.2 m, with performance noted at 46 L/min at 0 m and 28 L/min at 6 m head. With a stainless steel cutter, nitrile impeller, and compact 290 mm x 120 mm x 95 mm form factor, it suits holding tank, livewell, and fish box evacuation with 38 mm inlet and 25 mm discharge connections.
- Description
- Ask a Question
-
Jabsco 18590-2094 24V Macerator Pump Unit
The Jabsco 18590-2094 is a 24V macerator waste pump engineered for marine waste management. It is designed to grind waste into a slurry for smoother discharge and is described for use in onboard waste transfer setups such as holding tanks, livewells, and fish boxes.
Application
- Marine waste management and waste transfer
- Holding tanks (listed as ideal up to 680 liters; also stated as able to discharge tanks up to 600 liters in one operation)
- Livewells and fish boxes
Technical Specifications
Voltage 24V Output 46 L/min at 0 m; 28 L/min at 6 m head Self-Priming Up to 0.6 m vertical lift; also listed as up to 1.2 m Duty Cycle 15 minutes continuous Current Draw 8 A Recommended Fuse Size 15 A Connections Inlet: 38 mm; Discharge: 25 mm Port Types (Listed) Inlet: 38 mm (1-1/2") hose barb and 38 mm (1-1/2") NPT (male); Outlet: 25 mm (1") hose barb Dimensions (Listed) 290 mm x 120 mm x 95 mm; also listed as Height 9.2 cm x Width 11.9 cm x Length 29.4 cm Weight 2.19 kg Shipping Weight 2.80 kg Order Number 00320131 Supplier Code 18590-2094 Barcode 671880564380
Product Details
- Run-dry protection: listed as run-dry protection and short-term dry running possible
- Grinding system: newly designed 4-blade stainless steel chopper; stainless steel cutter reduces particle size to 3 mm (1/8") maximum
- Motor sealing: described as triple-sealed; also listed as an O-ring sealed motor
- Bearings: twin sealed ball bearings
- Impeller and wear components: oil-resistant nitrile impeller and stainless wearplate
- Fasteners: new version listed with long-lasting stainless bolts
- Motor label note: label on motor often shows No. 74001-2597
- Alternatives listed: 18590-0001, 18590-0091, 18590-1001, 18590-1091
Features
- Grinds waste into slurry to help support smooth discharge through the 25 mm (1") outlet
- Compact footprint for easier installation in onboard waste systems
- Sealed motor design described to help prevent corrosion
-
