Hydradrive Constant Velocity CV-Joint Drive Shaft for HD-108 to HD-142 Marine Propulsion Systems

Name: Hydradrive Constant Velocity CV-Joint Drive Shaft for HD-108 to HD-142 Marine Propulsion Systems
SKU: ALP 9099700

SKU: ALP 9099700

ID 1416297

$ 1,054.65

1-2 weeks delivery time

Type:

HD-125
HD-130
HD-142
HD-108 / HD-113
HD-115L

Length, mm:

Hydradrive constant velocity (CV) joint drive shafts for HD-108, HD-113, HD-115L, HD-125, HD-130 and HD-142 marine propulsion systems. Available in five configurations with nominal lengths from 155 to 270 mm, adjustable length tolerances of ±25 to ±45 mm, outside diameters from 103 to 213 mm and bolt circle diameters from 85 to 165 mm. Designed for torque transmission between the marine gearbox and propeller shaft assembly.

Description
Ask a Question

Hydradrive Constant Velocity CV-Joint Drive Shaft for HD-108 to HD-142 Marine Propulsion Systems

The Hydradrive Constant Velocity CV-Joint Drive Shaft is a component of Hydradrive marine propulsion systems, designed to transmit torque between the marine gearbox and propeller shaft assembly while accommodating angular differences between connected components.

The homokinetic drive shaft incorporates constant velocity joints and a variable-length arrangement, allowing installation between gearbox and thrust bearing connections with different mounting distances.

The range includes five drive shaft configurations for Hydradrive HD-108, HD-113, HD-115L, HD-125, HD-130 and HD-142 systems. Each version has specific length, outside diameter and bolt circle dimensions.

Key Features

Constant velocity transmission: Homokinetic joint construction for marine propulsion systems.
Angular flexibility: Accommodates angular displacement between connected shaft components.
Variable-length design: Different nominal lengths and adjustment ranges depending on the model.
Model-specific connections: Different external diameters and bolt circle dimensions.
Hydradrive compatibility: Versions for HD-108, HD-113, HD-115L, HD-125, HD-130 and HD-142.
Marine propulsion application: Designed for use within Hydradrive constant velocity shaft drive systems.

Technical Specifications

Parameter	Specification
Brand	Hydradrive
Product Type	Constant Velocity CV-Joint Drive Shaft
Application	Marine Propulsion Systems
Compatible Drive Models	HD-108, HD-113, HD-115L, HD-125, HD-130, HD-142
Nominal Shaft Length	155–270 mm, depending on model
Length Adjustment	±25 to ±45 mm, depending on model
Outside Diameter	103–213 mm, depending on model
Bolt Circle Diameter	85–165 mm, depending on model

Available Models and Dimensions

Article Number	Hydradrive Model	Nominal Length (mm)	Length Adjustment (mm)	Outside Ø (mm)	Bolt Circle Ø (mm)
9099700	HD-108 / HD-113	155	±25	103	85
9099710	HD-115L	170	±25	109.5	95
9099715	HD-125	210	±40	130	108
9099720	HD-130	245	±45	150	125
9099723	HD-142	270	±45	213	165

Model Compatibility

HD-108 / HD-113: Article 9099700, nominal length 155 mm, outside diameter 103 mm.
HD-115L: Article 9099710, nominal length 170 mm, outside diameter 109.5 mm.
HD-125: Article 9099715, nominal length 210 mm, outside diameter 130 mm.
HD-130: Article 9099720, nominal length 245 mm, outside diameter 150 mm.
HD-142: Article 9099723, nominal length 270 mm, outside diameter 213 mm.

Installation and Selection

The CV-joint drive shaft must be selected according to the Hydradrive drive system model and the installation dimensions between the gearbox and thrust bearing assembly.

Important selection parameters include:

Hydradrive Model: Compatibility with the existing drive system.
Nominal Length: Required drive shaft installation length.
Length Adjustment: Permitted variation around the nominal length.
Outside Diameter: External diameter of the CV-joint assembly.
Bolt Circle Diameter: Mounting connection dimension.

Before ordering, verify the required Hydradrive model, installation length and flange mounting dimensions.
