Osculati Adhesive-Lined Waterproof Heat Shrink Tubing, 3:1 Shrink Ratio

ID 1377224

$ 95.05

1-2 weeks delivery time

Diameter, mm:

Item:

Roll 10 m
Roll 5 m
Roll 12 m
Roll 8 m
Roll 3 m

The Osculati Adhesive-Lined Waterproof Heat Shrink Tubing is manufactured from cross-linked polyolefin and features an internal thermoplastic adhesive layer for sealing and waterproofing electrical connections. With a 3:1 shrink ratio, it provides excellent insulation, strain relief and environmental protection. Available in diameters from 6 mm to 24 mm.

Description
Ask a Question

Osculati 14.131.03-07 – Adhesive-Lined Waterproof Heat Shrink Tubing, 3:1 Shrink Ratio

The Osculati Waterproof Heat Shrink Tubing is manufactured from cross-linked polyolefin and incorporates an internal adhesive lining that melts during heating, creating a sealed and waterproof barrier around cables, terminals and electrical connections.

Its high 3:1 shrink ratio allows the tubing to accommodate a wide range of cable diameters while providing excellent environmental protection, electrical insulation and mechanical strength.

Key Features

Cross-linked polyolefin construction
Internal adhesive lining for waterproof sealing
3:1 shrink ratio
Protects electrical connections against moisture and corrosion
Provides insulation and strain relief
Black colour for professional installations
Suitable for marine, automotive and industrial applications

Available Variants

Osculati Code	Expanded Internal Diameter (mm)	Restricted Internal Diameter (mm)	Restricted Wall Thickness (mm)	Box Length (m)
14.131.03	6	2	1.1	12
14.131.04	9	3	1.3	10
14.131.05	12	4	1.7	8
14.131.06	18	6	2.0	5
14.131.07	24	8	2.5	3

Technical Specifications

Material	Cross-linked polyolefin
Adhesive Lining	Yes
Shrink Ratio	3:1
Colour	Black
Expanded Diameter Range	6-24 mm
Application	Waterproof sealing and insulation of electrical connections

Ideal for marine electrical systems, battery cables, wiring harnesses, terminal protection and any installation requiring a durable waterproof seal.
