The Vetus MPA34KBW25 aluminium engine panel is a 12 V second-generation unit featuring four white instruments, including a 0–5000 rpm tachometer with hour counter, temperature, oil pressure and voltage gauges, all integrated into a compact marine-grade anodized aluminium housing with an IP64 splash-proof front. The panel includes six warning lights, an acoustic alarm and a pre-heat/ignition switch with removable key, designed for dependable monitoring on dashboards with limited installation space.
- Description
- Ask a Question
-
Vetus MPA34KBW25 Aluminium Engine Panel 12V, 4 White Instruments, 0–5000 RPM, Second Generation
The Vetus MPA34KBW25 is a second-generation aluminium engine panel engineered for 12 V marine systems where precise engine monitoring and high durability are required. Equipped with four white gauges, including a 0–5000 rpm tachometer with integrated hour counter, the panel provides essential readouts in a robust, compact and visually refined housing. Made from marine-grade anodized aluminium and featuring an IP64 splash-proof front, it is suited for a wide range of helm station configurations.
Key Features
- Second-generation Vetus MPA34 engine panel for 12 V installations
- Four white instruments for core engine monitoring
- 0–5000 rpm tachometer with integrated hour counter
- Temperature, oil pressure and voltage gauges
- Six LED warning lights for critical engine conditions
- Acoustic alarm for enhanced operational safety
- Pre-heat/ignition switch with removable key
- IP64 splash-proof protection on the front side
- Marine-grade anodized aluminium construction for long-term reliability
- Compact format suitable for dashboards with limited installation depth
Technical Specifications
Parameter Value Model Vetus MPA34KBW25 Voltage 12 V DC Number of instruments 4 white instruments Tachometer range 0–5000 rpm with integrated hour counter Additional gauges Engine temperature, oil pressure, voltmeter Warning indicators Six LED warning lights Acoustic alarm Included Ignition system Pre-heat/ignition switch with removable key Front protection rating IP64 (splash-proof front face) Material Marine-grade anodized aluminium
Included Instruments
- Tachometer: 0–5000 rpm with hour counter
- Voltmeter: battery voltage monitoring
- Oil pressure gauge: real-time engine oil pressure indication
- Temperature gauge: engine cooling temperature monitoring
- Warning system: six LED warning indicators plus acoustic alarm
Design and Installation
Built from marine-grade anodized aluminium, the MPA34KBW25 delivers long-lasting performance and a clean, modern appearance. Its compact design fits well in helm stations with restricted dashboard space, while the IP64 splash-proof front ensures protection against marine conditions. The unit supports straightforward front-side installation, making integration quick and efficient.
-
