ID
1310982
$ 235.77
1-2 weeks delivery time
-
+
H-shackle eyebolt 25,000kg is a heavy-duty galvanized shackle with a thick shoulder bolt for lifting extremely heavy loads safely. The shackle measures 45 mm in diameter, the bolt 50 mm, internal width 73 mm, internal length 178 mm, and it handles 25,000 kg with a safety factor of 6.
- Description
- Ask a Question
-
H-shackle Eyebolt 25.000kg
Galvanized H-shackle with thick shoulder bolt, engineered for lifting extremely heavy loads with a high safety factor.
- Complies with EN 13889 standard
- Safety factor 6 (minimum breaking load is 6 x working load)
- Product code: 06.40.530
- Shackle diameter: 45 mm
- Bolt diameter: 50 mm
- Approx. weight: 13.7 kg
- Internal width: 73 mm
- Internal length: 178 mm
- Safe working load: 25,000 kg
-
