Gleistein GeoSquare 8-Strand Square Braided Polyester Rope 12-40 mm, 100 m

ID 1387295

$ 429.47

1-2 weeks delivery time

Diameter, mm:

Color:

Black
White

Item:

Roll 100 m

Gleistein GeoSquare polyester rope with abrasion-resistant 8-strand square braided construction that does not harden in use. Designed for mooring applications, with 2.5% elongation at 10% of breaking load and supplied on 100 m reels. Available in the supplied range in Ø12, 14, 16, 18 and 40 mm diameters, with breaking loads from 3000 to 30600 kg and white or black versions depending on diameter.

Description
Ask a Question

Gleistein GeoSquare 8-Strand Square Braided Polyester Rope 12-40 mm, 100 m - White / Black

Gleistein GeoSquare Polyester is a square braided polyester rope designed for mooring applications. Its 8-strand square construction provides abrasion resistance and is designed not to harden during use. The rope has an elongation of 2.5% at 10% of breaking load and is supplied on 100 m reels.

Product Features

8-strand square braided polyester construction
Designed for mooring applications
Abrasion-resistant construction
Designed not to harden during use
Elongation at 10% of breaking load: 2.5%
Supplied on 100 m reels
Available in white and black depending on diameter

Technical Data

Brand	Gleistein
Series	GeoSquare Polyester
Construction	8-Strand Square Braid
Material	Polyester
Elongation at 10% Breaking Load	2.5%
Reel Length	100 m
Available Diameters	12 / 14 / 16 / 18 / 40 mm
Breaking Load Range	3000-30600 kg
Available Colors	White / Black

Available Versions

Diameter	Breaking Load	Weight / 100 m	Color	VDM / Reya SKU	EAN
12 mm	3000 kg	11 kg	White	CR210012	3477440009615
14 mm	4110 kg	14.8 kg	White	CR210014	3477440009639
14 mm	4110 kg	14.8 kg	Black	CR211014	3477440009646
16 mm	5220 kg	19.5 kg	White	CR210016	3477440009653
16 mm	5220 kg	19.5 kg	Black	CR211016	3477440009660
18 mm	7000 kg	24.5 kg	White	CR210018	3477440009677
18 mm	7000 kg	24.5 kg	Black	CR211018	3477440009684
40 mm	30600 kg	121 kg	Black	CR40080	4063234028017
