The Osculati Electric Boat Trailer Winch is designed for boat hauling, service tenders, jet skis, and trailer applications. Available in 12V and 24V versions with pulling capacities from 1134 kg to 2400 kg, the winch features forward, idle, and reverse operation, a 5 m wired remote control, dynamic and mechanical braking systems, overload protection via circuit breakers, and a weather-resistant housing. Supplied with galvanized steel cable up to 6.3 mm × 15 m, the winches are powered by motors from 600 W to 1200 W.
- Description
- Ask a Question
-
Osculati Electric Boat Trailer Winch – 12V/24V, 1134-2400 kg Pull Capacity, Remote Control
The Osculati electric boat trailer winch range is designed for hauling boats, service tenders, jet skis and other trailer-mounted craft. These electric winches combine high pulling power with reliable control and integrated safety systems for launching and recovery operations.
Each winch features forward, idle and reverse gear functions, a wired remote control with a 5 m cable, dynamic and mechanical braking systems, overload protection through integrated circuit breakers, and a weather-resistant housing suitable for marine environments.
The range includes 12V and 24V models with pulling capacities from 1134 kg up to 2400 kg.
Key Features
- Electric boat trailer winch
- Available in 12V and 24V versions
- Forward, idle and reverse operation
- 5 m wired remote control included
- Cable guide rollers
- Dynamic and mechanical braking systems
- Circuit breaker overload protection
- Weather-resistant housing
- Supplied with galvanized steel cable
- Suitable for boats, tenders and jet skis
Technical Specifications
Code Voltage Max Pulling Power (kg) Motor Power (W) Current Draw (A) Galvanized Cable Dimensions (mm) Weight (kg) 02.151.11 12V 1134 600 30-200 4.8 mm x 15 m 423 x 153 x 197 17.5 02.251.11 12V 1588 900 25-300 5.5 mm x 15 m 423 x 153 x 197 17.9 02.351.11 12V 2400 1200 25-330 6.3 mm x 15 m 423 x 153 x 197 18.2 02.351.24 24V 2400 1200 10-170 6.3 mm x 15 m 423 x 153 x 197 18.2
Performance Overview
Model Maximum Traction (kg) Cable Speed / Current Consumption 02.151.11 1134 5.0 m/min / 30 A 02.251.11 1588 6.5 m/min / 25 A 02.351.11 2041 6.5 m/min / 25-10 A 02.351.24 2041 6.5 m/min / 25-10 A
Applications
- Boat trailer loading and recovery
- Jet ski trailers
- Service tender hauling
- Small workboats and utility craft
- Marine launching systems
-
