Tecnoseal 6AW-1132R-00 Yamaha Crankcase Cylinder Zinc Anode 300–350 HP

Name: Tecnoseal 6AW-1132R-00 Yamaha Crankcase Cylinder Zinc Anode 300–350 HP
SKU: Tecnoseal 01172
Price: 47.601260069976 USD
Availability: InStock

ID 1405622

$ 47.60

1-2 weeks delivery time

- +

Add to cart

The Tecnoseal 01172 is a zinc sacrificial internal engine anode designed for Yamaha 300–350 HP outboard motors, identified as Anode 6 in the Tecnoseal catalogue and corresponding to Yamaha OEM part number 6AW-1132R-00. It helps protect metallic components within the crankcase and cylinder assembly against corrosion. The anode features a cylindrical body with a hexagonal projection and an M5 threaded mounting hole. Its catalogue dimensions are 16 mm (a), 8 mm (b), 20 mm in overall height (h) and 16 mm in outside diameter (Ø). Manufactured from zinc, it weighs 0.02 kg (0.04 lbs).

Description
Ask a Question

Tecnoseal 6AW-1132R-00 Yamaha Crankcase Cylinder Zinc Anode 300–350 HP

The Tecnoseal 01172 is a zinc sacrificial internal engine anode designed for Yamaha 300–350 HP outboard motors. Identified as Anode 6 in the Tecnoseal catalogue and corresponding to Yamaha OEM part number 6AW-1132R-00, this replacement anode helps protect metallic components within the engine crankcase and cylinder assembly against corrosion.

The anode features a cylindrical zinc body with a hexagonal projection on one end and an internal M5 threaded mounting hole. Its cylindrical profile and hexagonal feature correspond to the component illustrated in the Tecnoseal catalogue. This configuration is intended for the specified Yamaha internal engine installation position.

The zinc material functions as a sacrificial corrosion protection component, corroding preferentially to help reduce galvanic corrosion of surrounding protected metallic engine components. The anode should be inspected and replaced according to Yamaha's maintenance recommendations.

According to the Tecnoseal catalogue, the anode has an outside diameter of 16 mm (0.63 in), an overall height (h) of 20 mm (0.79 in), dimension (a) of 16 mm (0.63 in) and dimension (b) of 8 mm (0.31 in). The internal mounting thread is M5. The zinc anode weighs 0.02 kg (0.04 lbs).

Technical Specifications

Manufacturer	Tecnoseal
Product Code	01172
Product Type	Internal Engine Sacrificial Anode
Material	Zinc
Application	Crankcase / Cylinder Assembly
Compatible Manufacturer	Yamaha
Compatible Engine Power	300–350 HP
Catalogue Designation	Anode 6
Yamaha OEM Reference	6AW-1132R-00
Construction	Cylindrical body with hexagonal projection
Mounting Thread	M5
Weight	0.02 kg (0.04 lbs)
EAN	8052744983837

Dimensions and Mounting Specifications

Dimension	Metric	Imperial
Outside Diameter (Ø)	16 mm	0.63 in
Overall Height (h)	20 mm	0.79 in
Dimension (a)	16 mm	0.63 in
Dimension (b)	8 mm	0.31 in
Thread (m)	M5	—

Compatibility and OEM Cross-References

Compatible Manufacturer: Yamaha
Outboard Power Range: 300–350 HP
Installation Area: Internal crankcase / cylinder assembly
Catalogue Designation: Anode 6
Yamaha OEM Part Number: 6AW-1132R-00
Tecnoseal Reference: 01172

Key Features

Designed for compatible Yamaha 300–350 HP outboard motors.
Corresponds to Yamaha OEM part number 6AW-1132R-00.
Identified as Anode 6 in the Tecnoseal catalogue.
Zinc sacrificial anode for internal engine corrosion protection.
Cylindrical body with a hexagonal projection.
Internal M5 threaded mounting connection.
Helps protect metallic crankcase and cylinder components against galvanic corrosion.
Outside diameter: 16 mm.
Overall height: 20 mm.
Catalogue dimensions a = 16 mm and b = 8 mm.
Weight: 20 g.

Compatibility Note: Before ordering, verify the Yamaha engine model, OEM part number 6AW-1132R-00 and original anode dimensions. Compare the cylindrical body, hexagonal projection and M5 threaded connection with the existing component. The stated 300–350 HP range does not imply compatibility with every Yamaha engine within that power range.
