ID
1259182
$ 57.67
1-2 weeks delivery time
-
+
The Rule 35A automatic bilge float switch is a compact, mercury-free switch for marine bilge pump control in tight spaces. It is rated to 14A and supports 12V to 24V DC systems, with mounting options for loose installation or mounting on a bilge pump. Key details include 110mm height at maximum lift, 51mm fixing-hole center spacing, detachable mounting base, and a listed product weight of 0.1 kg.
- Description
- Ask a Question
-
Rule 35A Automatic Bilge Float Switch
The Rule 35A is a narrow, mercury-free float switch designed to provide automatic on/off control of bilge pumps in marine environments. Its design is intended to reduce rapid on/off cycling and support dependable pump operation, including installations where space is limited.
Technical Specifications
Model 35A Order Number 00304481 Barcode 042237095435 Voltage Range 12V to 24V DC Maximum Current Rating 14A Current Limit (By Voltage) Up to 14A (12V) / 7A (24V) Switching Points Turns pump on at 51mm (2 in) water level; turns pump off at 19mm (3/4 in) water level Height at Maximum Lift 110mm (4.3 in) Fixing Hole Center Distance 51mm Dimensions (Listed) Length 127mm, Width 40mm, Height 110mm Dimensions (Additional Listing) Length 105mm, Width 40mm Dimensions (Additional Listing) Height 5.7 cm, Length 12.7 cm, Width 5.8 cm Packaged Dimensions 14.00 x 11.00 x 14.00 cm Operating Temperature Range -10°C to 60°C (14°F to 140°F) Switching Mechanism Mechanical float switch with durable internal contacts Construction Material High-quality, corrosion-resistant plastic Mounting Options Loose or on bilge pump Product Weight 0.1 kg Shipping Weight 0.30 kg Supplier Code 35A
Compatibility
- Bilge pump systems using 12V to 24V DC power
- Pumps drawing up to 14A (12V)
- Pumps drawing up to 7A (24V)
Features
- Mercury-free design
- Designed to help reduce rapid on/off cycling
- Compact/narrow profile intended for tight bilge spaces
- Detachable mounting base for installation, cleaning, and inspection
- Corrosion-resistant construction with waterproof grommet protection and blocked wiring
- Optional fuse holder available
Product Details
This float switch is intended for automatic bilge pump control and can be mounted either independently or directly on a bilge pump, depending on the installation needs.
-
