Gori 22x13x3LHx1:10W Folding Propeller – 3-Blade, Ø22", Pitch 13", Left-Hand, for 40 mm ISO Shaft

ID 831282

1-2 weeks delivery time

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Gori 22x13x3LHx1:10W is a 3-blade folding propeller (Ø22", pitch 13", left-hand) for 40 mm ISO shafts. Equipped with Overdrive pitch control, curved blades for powerful forward/reverse thrust, and a low-drag folded profile. Suitable for 10–300 hp engines. Built from Nibral and stainless steel.

Description
Ask a Question

Gori 22x13x3LHx1:10W Folding Propeller – 3-Blade, Ø22", Pitch 13", Left-Hand, for 40 mm ISO Shaft

The Gori 22x13x3LHx1:10W folding propeller is a high-performance 3-blade solution for sailing yachts and motor sailers using 40 mm ISO shafts. Introduced in 1994 and awarded both the DAME and HISWA Awards, it set a new standard in yacht propulsion.

Technical Specifications
- Diameter: Ø22"
- Pitch: 13"
- Blades: 3-blade, folding
- Rotation: Left-hand
- Shaft Compatibility: 40 mm ISO Shaft (1:10 taper)
- Engine Power Range: 10 hp to 300 hp (7 kW to 221 kW)
Key Features
- Overdrive Function: Enables the helmsman to adjust pitch and blade profile while underway for improved fuel efficiency and reduced engine noise and vibration.
- Superior Thrust: Unique wing curvature ensures optimal forward and reverse thrust, offering enhanced maneuverability over conventional designs.
- Efficiency: Independent tests show +15% improvement in both forward and reverse efficiency compared to standard folding or rotary blade propellers.
- Drag Reduction: When folded, the propeller maintains a low profile, minimizing drag and increasing sailing speed.
- Debris Protection: Blade geometry prevents seaweed and debris from entangling the propeller.
- No Shaft Brake Needed: Suitable for use with hydraulic gearboxes without requiring a separate shaft brake.
Construction and Quality

Manufactured using corrosion-resistant Nibral and stainless steel, every Gori propeller is individually numbered for traceability, quality assurance, and future service needs. With over 25 years of market leadership, Gori remains a trusted name for yacht builders, designers, and regatta sailors.
