ID
1351237
$ 2,540.81
1-2 weeks delivery time
-
+
The Aquadrive 6070049 CV21 Extended Constant Velocity Joint is a custom-length drivetrain coupling designed for Aquadrive CVB21.10 and CVB21.20 propulsion systems, supporting working lengths up to 1000 mm. It enables smooth torque transmission and flexible shaft alignment within marine drivetrain installations. The unit is supplied as 1 piece, identified by product number 6070049 and EAN 8720193043180.
- Description
- Ask a Question
-
Aquadrive 6070049 – CV21 Extended Constant Velocity Joint, Custom Length up to 1000 mm, for CVB21.10 / CVB21.20
The Aquadrive 6070049 CV21 Extended Constant Velocity Joint is a drivetrain coupling designed for Aquadrive propulsion systems. It supports reliable torque transmission while allowing flexible shaft alignment within the propulsion drivetrain.
This extended version of the CV21 joint is intended for installations requiring longer shaft connections and supports a maximum working length of up to 1000 mm. It is specifically compatible with Aquadrive CVB21.10 and CVB21.20 systems, ensuring proper integration within the drivetrain assembly.
The constant velocity joint design maintains consistent rotational speed between connected shafts while allowing controlled angular movement, supporting smooth power transmission and stable drivetrain operation.
Key Features
- Extended constant velocity joint for Aquadrive propulsion systems
- Maximum working length up to 1000 mm
- Compatible with Aquadrive CVB21.10 and CVB21.20 drivetrain systems
- Provides smooth torque transmission between connected shafts
- Allows flexible shaft alignment within the drivetrain
- Precision drivetrain component manufactured by Aquadrive
Technical Specifications
Product Name Aquadrive CV21 Extended Constant Velocity Joint Product Number 6070049 Brand Aquadrive Type Extended Constant Velocity Joint Maximum Working Length Up to 1000 mm Compatible Systems CVB21.10, CVB21.20 EAN Code 8720193043180 Sales Unit 1 piece -
