Lopolight 101-004 - Port-Starboard Combination Navigation Light 112.5° 1 NM

ID 1341409

$ 589.48

1-2 weeks delivery time

- +

Add to cart

The Lopolight 101-004 combination navigation light offers vertical-mount red and green LED signals for vessels up to 20 m. It provides full brightness from 10 to 32 V, ultra-compact anodized aluminum housing, IP68+ waterproof protection, anti-vibration epoxy encapsulation, and meets international navigation regulations.

Description
Ask a Question

Lopolight 101-004 - Port-Starboard Combination Navigation Light 112.5° 1 NM

The Lopolight 101-004 port-starboard combination navigation light is developed to the highest quality standards and fully assembled and individually tested in Denmark. Designed for vessels from 0 to 20 m, this ultra-compact vertical-mount light delivers full brightness from 10 to 32 V with very low power consumption.

Its anodized aluminum housing and epoxy-embedded electronics provide excellent protection against vibration, water ingress, and electromagnetic interference, ensuring reliable performance in demanding marine environments.

Key Features

Port and starboard two-tone navigation light
Ultra-compact vertical mounting design
Full brightness from 10 to 32 V
IP68+ vacuum-rated waterproof protection
Anti-vibration epoxy resin encapsulation
No VHF/AIS electromagnetic disturbance
5-year worldwide warranty

Technical Data

Type	Two-Tone Navigation Light
Lighting Color	Green / Red
Angle	112.5°
Range	1 NM
Voltage	10–32 V
Consumption	87 mA
Lighting Technology	LED
Fixation	Vertical
Boat Length	0–12 m
Material	Anodized Aluminum
Color	Anodized Aluminum
Ingress Protection	IP68
Width	73.16 mm
Length	74.55 mm
Height	28 mm
Homologation	COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR

Brand: Lopolight
Article code: 101-004
