The Isotherm SED00035GA Power Pack converts 230V AC (47/63Hz) to 24V DC for powering Isotherm DR160 drawer refrigerators and freezers equipped with BD80F compressors. Delivering up to 200W / 8.5A output power, it ensures stable voltage, quiet operation, and high efficiency for marine or RV electrical systems. Designed for global use, it supports 230V input at up to 2.5A, offering safe, reliable operation even under fluctuating onboard power conditions.
- Description
- Ask a Question
-
Isotherm SED00035GA – Power Pack 230V 47/63Hz 24V DC for DR160 Drawer Refrigerator/Freezer (BD80F Compressor)
The Isotherm SED00035GA Power Pack is a high-performance AC/DC converter designed for marine and mobile applications. It supplies stable 24V DC output to power Isotherm DR160 drawer refrigerators and freezers that use the Secop BD80F compressor. Supporting 230V AC input at 47–63Hz, this power module enables operation from shore power or onboard AC generators, ensuring reliable performance and efficient refrigeration under all conditions.
Key Features
- Converts 230V AC to 24V DC for Isotherm DR160 refrigerator/freezer models
- Compatible with Secop BD80F compressors
- Supports 47–63Hz frequency range for worldwide operation
- Provides up to 200W / 8.5A maximum output power
- Compact and lightweight design suitable for marine installations
- High efficiency and low heat generation for safe operation
- Stable voltage output protects compressor electronics
Technical Specifications
Parameter Value Part Number SED00035GA Product Type AC/DC Power Pack Input Voltage 230V AC, 47–63Hz Input Current 2.5A max. Output Voltage 24V DC Output Current 7A nominal / 8.5A max. Maximum Output Power 200W Compatible Compressor Secop BD80F Application Isotherm DR160 Drawer Refrigerator / Freezer
Applications
- Marine refrigeration systems (Isotherm DR160 models)
- RV and camper refrigeration powered from AC mains
- Onboard AC/DC power conversion for cooling units
-
