The Victron SmartShunt 300A (SHU050130050) is a compact, display-free battery monitor with built-in Bluetooth and VE.Direct communication. It supports 6.5–70V DC systems and integrates seamlessly with the VictronConnect app or GX devices. This all-in-one shunt-based solution tracks voltage, current, state of charge, amp-hours, and time remaining—ideal for clean, space-saving installations.
- Description
- Ask a Question
-
Victron Energy SmartShunt 300A Battery Monitor (SHU050130050) is a fully-featured, compact battery monitor that eliminates the need for a separate display. It uses Bluetooth or VE.Direct to communicate with your smartphone, tablet, or GX device, making it ideal for clean, clutter-free installations. The SmartShunt accurately tracks key battery metrics including voltage, current, state of charge, time-to-go, and amp-hours consumed.
Technical Specifications:
Model SHU050130050 (SmartShunt 300A) Supply Voltage 6.5 – 70 VDC Battery Capacity 1 – 9999 Ah Shunt Rating 300A / 50mV Current Draw < 1 mA (standby) Aux Input Yes – second battery voltage, midpoint, or temperature sensor Temperature Range -40 to +50°C (operation), -20 to +50°C (sensor input) Communication Interfaces Bluetooth, VE.Direct Dimensions (HxWxD) 44 × 120 × 44 mm Shunt Connection Bolts M8 Protection Rating IP21
Accuracy & Resolution:
- Voltage: ±0.01 V (±0.3%)
- Current: ±0.01 A (±0.4%)
- Amp-hours: ±0.1 Ah
- State of charge: ±0.1%
- Time-to-go: ±1 minute
- Temperature (optional sensor): ±1°C / ±1°F
Key Features:
- Bluetooth-enabled for wireless monitoring via VictronConnect app.
- VE.Direct port for integration with GX systems (e.g., Cerbo GX).
- Tracks voltage, current, power, amp-hours, SOC, and more.
- Aux input supports temperature, midpoint, or second battery monitoring.
- Clean, display-free design ideal for minimal and remote installations.
- Stores 46 days of historical battery trend data.
Included Accessories:
- Two fused cables for battery '+' and auxiliary input (1A fuse)
Typical Applications:
- Marine, RV, and vehicle battery systems
- Off-grid solar and backup power systems
- Industrial battery monitoring where space is limited
Note: For systems requiring a display or relay output, consider the Victron BMV-712 Smart. If Bluetooth signal is weak (e.g., in metal enclosures), a VE.Direct Bluetooth Dongle can be added externally.
