Victron Energy PMP121500100 - MultiPlus 12/500/20-16 120V VE.Bus Inverter/Charger

SKU: CN VIPMP121500100

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron MultiPlus 12/500/20-16 is a compact, multifunctional inverter/charger offering 500 VA of continuous power at 120V AC with a 20 A charger. Ideal for mobile and off-grid applications, it features a true sine wave inverter, adaptive battery charger for multiple battery chemistries, PowerAssist functionality, and remote monitoring via VE.Bus.

Description
Ask a Question

Victron Energy MultiPlus 12/500/20-16 120V VE.Bus Inverter/Charger is a reliable, compact, and powerful device that integrates a pure sine wave inverter, adaptive battery charger, and high-speed AC transfer switch in one unit. It is ideal for applications where space, flexibility, and reliable energy conversion are essential.

Main Features:

True sine wave inverter with 500 VA continuous power output
Adaptive 4-stage 20 A battery charger with support for Lithium, AGM, Gel, Flooded and Sealed batteries
High-speed 16 A transfer switch
PowerAssist and PowerControl functions to optimize shore/generator power usage
Parallel and three-phase capability (up to 6 units)
VE.Bus communication for remote system integration and configuration
Search Mode for ultra-low standby power consumption (2 W)
Programmable relay for alarms or generator control
Remote monitoring and configuration via Victron VRM portal and VictronConnect app

Technical Specifications:

Function	Specification
Model	MultiPlus 12/500/20-16
Inverter Continuous Output Power (25°C)	500 VA / 430 W
Peak Power	900 W
AC Output Voltage / Frequency	120 V ±2% / 60 Hz ±0.1%
DC Input Voltage Range	9.5 - 17 V
Charger Output Current (House Battery)	20 A
Charger Output Current (Starter Battery)	1 A
Battery Charge Voltages	Absorption: 14.4 V, Float: 13.8 V, Storage: 13.2 V
Zero-load Power / Search Mode	6 W / 2 W
Efficiency	90%
Transfer Switch	16 A
Protection	Short circuit, Overload, Battery over/undervoltage, Overtemperature, Ripple input, 120 VAC feedback
Operating Temperature	-40 to +65°C (fan assisted)
Enclosure Material	Steel/ABS, Blue (RAL 5012)
Ingress Protection	IP21
Dimensions (H x W x D)	311 x 182 x 100 mm
Weight	4.4 kg
Communication Port	VE.Bus (RJ45)

Remote Monitoring & Accessories:

VE.Bus Smart Dongle – Enables Bluetooth control and monitoring
VictronConnect App – Available for iOS/Android for local configuration and monitoring
Cerbo GX / Ekrano GX – For advanced remote control and system integration
VRM Portal – Free Victron cloud platform for remote access, alarms, and data logs

Applications: ideal for RVs, marine vessels, off-grid homes, and backup systems.

Part Number: PMP121500100
Brand: Victron Energy
