Victron Energy BMV-710H Smart Battery Monitor (BAM030710100) is a high-precision monitoring device engineered for high-voltage battery systems (60–385V DC). It features integrated Bluetooth for wireless connectivity with the VictronConnect app, allowing quick access to detailed battery performance data including voltage, current, amp-hours consumed, state of charge, power, and time-to-go. Designed for demanding off-grid, telecom, or industrial systems, it includes a protected 500A/50mV shunt for safe high-voltage installation.
Technical Specifications:
Model BAM030710100 (BMV-710H Smart) Voltage Range 60 – 385 VDC Battery Capacity Range 1 – 9999 Ah Current Draw (Backlight Off) < 4 mA Shunt 500A / 50mV (included, in protective enclosure) Relay Output 60V / 1A, Normally Open Auxiliary Input Not available Communication Interfaces Bluetooth, VE.Direct Installation Type Flush mount (63mm front, 52mm body) Display Protection IP55 (indoor use)
Measurement Accuracy & Resolution (with 500A shunt):
- Voltage: ±0.01 V (±0.3%)
- Current: ±0.01 A (±0.4%)
- Amp-hours: ±0.1 Ah
- State of charge: ±0.1%
- Time to go: ±1 minute
Key Features:
- Bluetooth built-in — no dongle required.
- Designed for high-voltage systems up to 385V DC.
- Tracks amp-hours consumed, current, voltage, power, and SOC.
- Protected 500A/50mV shunt included for safe high-voltage use.
- VE.Direct interface for integration with GX devices or PC monitoring.
- Configurable relay for automation or alarms.
- Stores up to 46 days of historical data for analysis.
Included Components:
- BMV-710H Smart display unit
- 500A/50mV high-voltage shunt (protected housing)
- 10m RJ12 UTP communication cable
- 2m fused battery power cable
- Round and square bezels, mounting ring, and installation screws
Typical Applications:
- Off-grid solar or wind systems with high-voltage batteries
- Telecom or industrial backup systems (60–385V DC)
- Professional battery monitoring with wireless app access
Note: For midpoint voltage or temperature monitoring, use the BMV-702 or BMV-712 Smart. The BMV-710H Smart is designed for grounded-negative systems only. For balancing series-connected batteries, consider the Victron Battery Balancer (BMS012201000).
-
