€ 117,81
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The Victron ASS300420200 Zigbee to USB Converter pair enables wireless communication between energy meters and GX devices, eliminating the need for long RS485 wiring. With support for Zigbee 2007 protocol at 2460 MHz and USB-powered operation, it offers a reliable wireless bridge for energy monitoring systems, with up to 1600 meters of range.
- Description
- Ask a Question
-
Victron Energy Zigbee to USB Converter Pair (ASS300420200) provides a wireless solution for connecting RS485-based energy meters to Victron GX devices using a USB port. This plug-and-play converter pair replaces long RS485 cables with a Zigbee 2007 wireless link, offering robust, long-range connectivity up to 1600 meters line-of-sight.
Technical Specifications:
Model ASS300420200 Converter Type Zigbee to USB (Wireless Pair) Frequency Band 2460 MHz (default), adjustable 2405–2480 MHz in 5 MHz steps Communication Protocol Zigbee 2007 Transmission Distance Up to 1600 meters (line-of-sight) Baud Rate (UART) 9600 / 19200 / 38400 / 57600 / 115200 bps (default: 38400 bps) Power Supply Via USB port (5V DC) Current Consumption Send: 120mA max, Receive: 45mA max, Standby: 40mA max Interface USB to RS232 (2-TX, 3-RX, 5-GND) Size 70 × 50 × 24 mm
Key Features:
- Wireless bridge for connecting RS485 energy meters to GX devices via USB.
- Up to 1600 meters transmission range in open line-of-sight environments.
- Eliminates the need for long RS485 cabling in installations.
- Preconfigured Zigbee 2007 protocol with 2460 MHz channel.
- Plug-and-play operation powered through USB — no external power required.
Typical Applications:
- Wireless energy meter integration in Victron Energy Storage Systems (ESS).
- Remote monitoring of PV output or AC loads without RS485 wiring.
- Linking ET112, ET340, EM540 meters to Cerbo GX or Ekrano GX via USB.
Note: One converter should be connected to the USB port of the GX device, and the other to the RS485 terminal of the energy meter. No driver installation is required on Victron GX systems.
Documents
Victron Energy Zigbee to USB Converter Size: 2,1 Mb -
