VDO 150-035-006G - Cockpit International Pressure Gauge 10 Bar 52mm

SKU: VDO 150035006G

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The VDO 150-035-006G Cockpit International Pressure Gauge is a high-quality mechanical instrument designed for accurate oil pressure monitoring up to 10 Bar. Its compact 52mm panel hole diameter and durable M12 x 1.5 thread connection make it ideal for automotive, marine, and industrial applications. The black dial with a red pointer and optional floodlight illumination (white, green, or red) ensures excellent visibility in all lighting conditions. Built with IP64-rated front protection, the gauge is resistant to UV, ozone, and water splashes, offering reliable performance in harsh environments. Operating across a wide temperature range of -30°C to +85°C, it is built for durability with a flame-retardant housing and compliance with EN 13309 and ISO 13766 standards for electromagnetic compatibility. With its precise readings, robust construction, and versatile design, this pressure gauge is perfect for demanding systems requiring consistent and reliable pressure monitoring.

Description
Ask a Question

VDO 150-035-006G - Cockpit International Pressure Gauge 10 Bar 52mm

Key Features:
- Pressure range: 0 to 10 Bar with mechanical M12 x 1.5 connection
- Compact 52 mm (2 1/16 inch) installation diameter, ideal for versatile applications
- Single anti-glare lens with black dial and red pointer for optimal visibility
- Floodlight illumination with optional 12V (3.4W) or 24V (3W) lighting options
- Durable design with IP64 front protection against UV, ozone, and water splashes
- Triangular black threaded bezel for a sleek and secure fit
- EMC-tested to EN 13309 and ISO 13766 standards for electromagnetic compatibility
- Plastic flame-retardant housing designed for safety and durability
Specifications:
- Panel hole diameter: 52 mm (2 1/16 inches)
- Outside diameter: 59.25 mm (2 1/3 inches)
- Installation depth: 67.5 mm
- Locking height with bracket: 0.5 mm - 8 mm
- Thread connection: M12 x 1.5
- Operating voltage (illumination only): 12V standard, 24V optional
- Current consumption (illumination only): 12V 2W, 24V 2W
- Dial illumination: White, green, or red floodlight (optional)
- Pointer: Red with backlight
- Deflection angle: 90°
- Front protection class: IP64 (DIN 40050)
- Rear protection class: IP42 (DIN 40050)
- Operating temperature: -30°C to +85°C
- Mechanical shock resistance: Max 1G, 25Hz - 2000Hz (8 hours)
- Lens material: Single anti-glare
- Housing: Plastic flame-retardant
- Nominal position: NL 0 to NL 90 (DIN 16257)
Compatibility and Application:
- Designed for monitoring oil pressure in automotive, marine, and industrial systems
- Ideal for applications requiring precise mechanical pressure readings
- Compatible with systems utilizing M12 x 1.5 threaded connections
Benefits:
- Provides reliable and precise mechanical oil pressure monitoring
- Durable construction with IP64 front protection ensures long-lasting performance
- Optional floodlight illumination improves visibility in low-light environments
- Compact and easy to install with secure threaded bezel design
- Electromagnetic compatibility tested for use in sensitive environments
- Operates reliably across a wide temperature range, making it suitable for demanding conditions
