Mastervolt ChargeMaster Plus 24/60-3 battery charger offers efficient 3-stage+ charging for 24V systems, with multi-output support, Li-ion compatibility, and advanced monitoring features for marine use.
- Description
- Ask a Question
-
Mastervolt 44320605 - ChargeMaster Plus Battery Charger 24/60-3
The Mastervolt ChargeMaster Plus 24/60-3 battery charger delivers efficient and dependable charging performance for marine and onboard power systems. Designed to simplify electrical installations, it removes the need for additional chargers while supporting all battery technologies with an advanced 3-stage+ charging process.
The integrated pre-float function protects smaller batteries against overcharging, allowing batteries with different capacities to be charged simultaneously. A dedicated Li-ion charging profile is included for compatibility with modern battery systems.
Engineered for demanding environments, the charger withstands high temperatures and significant voltage fluctuations. Through MasterBus, CZone and NMEA2000 communication protocols, users can monitor charger performance, battery voltage and temperature. Remote monitoring and management are available when connected to a SmartRemote display (not included).
Technical Data
Model 24/60-3 Original Reference 44320605 Voltage 24 V Supply Voltage 120/230 V Battery Outputs 3 Battery Capacity 200-500 Ah Charging Method 3-stage+ charging Protection Rating IP23 Dimensions 384 x 250 x 127 mm Weight 5.9 kg Barcode 816882022524 Certifications CE, ABYC, UL, cULus, SAE, CEC/DOE, ISO 8846, ACMA
Brand: Mastervolt
-
