ID
1305850
$ 1,848.28
1-2 weeks delivery time
-
+
A 12V 90A Dolphin Pro Evo battery charger with TOUCHVIEW control, CANbus connection, and aluminum casing. It operates up to 50°C, displays charging data and alarms, supports 350-900 Ah batteries, and has four isolated full-power outputs.
- Description
- Ask a Question
-
Trem L0699454 - Battery Charger Dolphin Pro Evo 12V 90A
Unit features TOUCHVIEW control, CANbus connection, marinized circuitry, aluminum case, and sustained performance up to 50°C/122°F. Charging data and alarms appear on the integrated panel, and the model meets ISO 8846 and SAE J1171 requirements.
- Weight: 3,50 Kg
- Fixing: 4 walls x M4 screws
- Mod.: 12V 90A
- Fuse: T20A
- Max consumption: 1450VA
- Input voltage: 115V/230V (+/-15%) Automatic switch
- Dolphin CODE: 399454
- Frequency: 50Hz/60Hz (+/-10%)
- Yield: 92%
- Number of outputs: 4 Isolated (Full Power)
- Max Amp (+/-5%): 90A
- Battery capacity: 350-900 Ah
- Display: LED Panel (State of charge, Power, Alarms)
- Brand: Dolphin Charger
- EAN: 8024827800690
-
