The Blue Sea 2356 is a water-resistant busbar rated for 100 A AC/DC, supporting 300 V AC and 48 V DC, featuring a tin-plated copper C11000 bus, one #10-32 terminal stud, four #8-32 terminal screws, IP66 protection, and mounting via 1/4" (6 mm) screws, with defined input and load wire size ranges.
- Description
- Ask a Question
-
Blue Sea 2356 – Water-Resistant BusBar 100A, 300V AC / 48V DC, IP66
The Blue Sea 2356 Water-Resistant BusBar is designed for electrical distribution in harsh environments where moisture protection is required. Its sealed construction supports standard ring or spade terminals while maintaining water-resistant performance.
Key Features
- Water-resistant busbar for DC and AC distribution
- IP66 rated enclosure for protection against water ingress
- Tin-plated copper bus for electrical conductivity
- Accepts standard ring or spade terminals
- Includes wire plugs to maintain water-resistant rating when unused ports are present
- Compatible with other Water-Resistant 100A BusBars and ST-Blade Water-Resistant Fuse Blocks
Electrical Specifications
Continuous Rating 100 A AC / 100 A DC Maximum Voltage 300 V AC / 48 V DC Bus Material Tin-plated copper C11000
Connection & Mounting
Terminal Stud 1 × #10-32 Terminal Screws 4 × #8-32 Mounting Holes Accepts 1/4" (6 mm) screws
Wire Size Capacity
Input (1) 8 AWG to 4 AWG Load Outputs (4) 16 AWG to 10 AWG
Additional Details
- Cover included
- Includes three wire plugs
- Includes four write-on circuit labels
Compliance
- CE Marked
- IP66
Related Products
- Water-Resistant 100A BusBar Manual Cover (PN 2356100)
- ST-Blade Water-Resistant Fuse Block (PN 5056)
- ST-Blade Water-Resistant Fuse Block Manual Cover (PN 5056100)
-
