The BEP 778-T2S-400 is a Pro Installer Class-T fuse holder designed for high-power marine circuits requiring extremely fast fuse blow characteristics. It accepts Class-T fuses (JLLN / TJN / A3T) in the 225–400A range (amperage determined by fuse sizing) and is rated for 50V DC systems. The holder features 10 mm (3/8") cable connection studs and 10 mm (3/8") fuse mounting studs, and includes a clear polycarbonate cover plus a high-temperature, fiber reinforced plastic base for strength and chemical resistance. It uses tinned CDA102 copper conductors and stainless steel studs, washers, and nuts with metric threads for long service life in harsh marine environments, and is listed with OEM reference 778-T2S-400-B with a 1.5× footprint.
- Description
- Ask a Question
-
BEP 778-T2S-400 – Pro Installer Class-T Fuse Holder with Cover, 225–400A, 50V DC, 10 mm (3/8") Studs, JLLN / TJN / A3T
The BEP 778-T2S-400 is a Pro Installer Class-T fuse holder designed to provide ultimate protection for high power circuits where extremely fast fuse blow characteristics are required. It is intended for modern onboard electrical systems where high short circuit currents may exceed the interrupt rating of standard circuit breakers or other fuse types.
Key Features
- Fuse holder type: Class-T fuse holder
- Fuse compatibility: Class-T (JLLN / TJN / A3T)
- Current range: 225–400A (determined by fuse sizing)
- Voltage rating: 50V DC
- Clear polycarbonate cover
- High temperature, fiber reinforced plastic base for strength and chemical resistance
- Tinned CDA102 copper conductors
- Stainless steel studs, washers and nuts for longevity in the marine environment
- Metric threads
Stud / Connection Specifications
Cable Connection Studs 10 mm (3/8") studs Fuse Mounting Studs 10 mm (3/8")
Model Reference
Description Fuse Holder, Class-T 225–400A Part Number 778-T2S-400 OEM Reference 778-T2S-400-B Footprint 1.5× -
