ID
1317282
$ 489.90
1-2 weeks delivery time
-
+
Wika Bourdon tube pressure gauges with stainless steel measuring systems are designed for precise measurement of gases and liquids in pneumatic, hydraulic, shipping, chemical, and food sectors. They include a 160 mm stainless steel 304 case with bottom connection and back flange, a white dial with black lettering, a black pointer, a safety glass or polycarbonate window, and glycerine filling. These gauges adhere to accuracy class 1.0 according to DIN 16005 and measure from -1 to +3 bar.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 160mm Bottom Connection With Back Flange 1/2'' -1 + 3 Bar
Wika Bourdon tube pressure gauges with stainless steel measuring systems are designed for precise measurement of gases and liquids in pneumatic, hydraulic, shipping, chemical, and food sectors. These gauges adhere to accuracy class 1.0 according to DIN 16005.
- Case: Ø 160 mm with bottom connection and back flange
- Case material: Stainless steel 304
- Measuring system: 316Ti stainless steel
- Dial: white with black lettering
- Pointer: black
- Window: safety glass/polycarbonate
- Case fill: glycerine
- Dimensions: as per DIN16064
- Product code: 40.27.306
- Connection: 1/2" BSP bottom connection with back flange
- Measuring range: -1 + 3 bar
-
