Gebo Deck Hatch Rectangular class AI Low Profile

€ 418,25

1-2 weeks delivery time
Price incl. 19% VAT

Size, mm:

450x320
500x370
620x620
260x260
470x470
325x185
495x495
275x275
310x310
420x420
440x440
510x510

Low-profile hatches have an aesthetically attractive appearance and are perfectly combined with smooth, smooth lines of today's design. The hatches are made of the highest quality seawater resistant materials, namely anodized aluminum. All other parts, including loops and handles, are also made of corrosion resistant materials. The sealing material is made of silicone rubber.

Description
Ask a Question

Low profile Gebo rectangular hatches:

SKU	Cut Sizes	Cut Fillet Radius	External Dimensions	Outside fillet radius	Acrylic Glass Thickness
80.50.26.00	260 x 260 mm	42 mm	315 x 315 mm	70 mm	8 mm mm
80.50.30.00	275 x 275 mm	42 mm	330 x 330 mm	70 mm	8 mm
80.50.31.00	310 x 310 mm	42 mm	365 x 365 mm	70 mm	8 mm
80.50.35.00	325 x 185 mm	42 mm	380 x 240 mm	70 mm	8 mm
80.50.60.00	420 x 420 mm	42 mm	475 x 475 mm	70 mm	8 mm
80.50.40.60	440 x 440 mm	42 mm	495 x 495 mm	70 mm	8 mm
80.50.40.01	450 x 320 mm	42 mm	505 x 375 mm	70 mm	8 mm
80.50.80.00	470 x 470 mm	42 mm	525 x 525 mm	70 mm	8 mm
80.50.01.29	495 x 495 mm	95 mm	550 x 550 mm	123 mm	10 mm
80.50.70.50	500 x 370 mm	42 mm	555 x 425 mm	70 mm	8 mm
80.55.90.00	510 x 510 mm	42 mm	565 x 565 mm	70 mm	10 mm
80.55.10.00	620 x 620 mm	42 mm	675 x 675 mm	70 mm	10 mm
