ID
1307458
$ 6.90
1-2 weeks delivery time
-
+
The Osculati 13.183.13 LED Courtesy Light is a compact marine lighting fixture designed for 12V onboard electrical systems. Manufactured from transparent polycarbonate, the fixture provides blue courtesy illumination using a single LED delivering 2 lumens output with a wide 120° beam angle while consuming only 0.2W of power. Designed for through-mounted recessed installation, the light requires a 20 mm mounting hole and features Ø33 mm external diameter with 5 mm overhang. The IP67-rated waterproof construction makes the fixture suitable for cockpit seating, companionways, stairways, deck passages, and decorative marine ambient lighting applications.
- Description
- Ask a Question
-
Osculati 13.183.13 Clear Blue LED Courtesy Light Ø33 mm Recess Mount IP67
The Osculati 13.183.13 LED courtesy light is a compact marine lighting fixture developed for onboard ambient and courtesy illumination applications. Designed for 12V electrical systems, the fixture combines minimal power consumption with waterproof marine-grade construction.
The housing is manufactured from transparent polycarbonate material, providing lightweight corrosion-resistant construction suitable for marine interior and exterior installations.
The fixture incorporates a single blue LED producing 2 lumens output with a wide 120° beam angle for smooth ambient light distribution. The lighting configuration is suitable for companionways, cockpit seating, stairways, deck passages, and decorative onboard illumination.
Operating with ultra-low 0.2W power consumption, the fixture provides efficient onboard courtesy lighting while minimizing electrical load.
The recessed through-mount installation requires a 20 mm mounting hole and features compact Ø33 mm external diameter with only 5 mm overhang, allowing discreet integration into onboard surfaces.
The IP67-rated waterproof construction protects against dust ingress and temporary immersion, ensuring dependable operation in demanding marine environments.
Main Features
- Compact marine LED courtesy light
- Suitable for 12V electrical systems
- Transparent polycarbonate housing
- Blue LED illumination
- Single LED configuration
- 2 lumens light output
- Wide 120° beam angle
- Ultra-low 0.2W power consumption
- Recessed through-mount installation
- Compact low-profile design
- IP67 waterproof protection
- Suitable for interior and exterior marine applications
Technical Specifications
Brand Osculati Osculati Code 13.183.13 Product Type LED Courtesy Light Operating Voltage 12V Power Consumption 0.2W Luminous Output 2 Lumens LED Quantity 1 LED Light Colour Blue Beam Angle 120° Body Material Transparent Polycarbonate Installation Type Recess Mount / Through Mount Protection Rating IP67 Recess Diameter 20 mm External Diameter Ø33 mm Overhang 5 mm -
