ID
1345450
$ 446.84
1-2 weeks delivery time
-
+
The Exalto EWT 223BS 12V 65° wiper motor delivers extended wiping coverage for 75 mm bulkhead installations. It includes a pendulum arm type, speed interval control, self-parking, and 23 Nm torque for consistent performance.
- Description
- Ask a Question
-
Exalto EWT Wiper 223BS 12V 65° 23Nm Bulkhead 75mm
The Exalto EWT 223BS 65° wiper motor provides extended wiping coverage while maintaining a robust design for 75 mm bulkhead mounting. Part of the MD1 series, this 12V DC motor includes speed interval control, self-parking, and a pendulum arm type for dependable performance.
Key Features
- 65° angle of view
- Pendulum arm type
- Speed interval and self-parking
- Ungrounded 12V DC design
- Designed for 75 mm bulkhead thickness
Technical Data
Sales Unit 1 piece Series MD1 Suitable For MD1 series Voltage (V) 12 Type VDC Power (W) 36 Torque (Nm) 23 Angle Of View (°) 65° Driven Axles 1 High Speed (rpm) 60 Low Speed (rpm) 40 Maximum Amperage (A) 3 Recommended Fuse Rating (A) 6 Drive Shaft Diameter (mm) 19 Shaft Length (mm) 131 Distance HoH (mm) 50 Support Diameter (mm) 6.4 Wall Thickness (mm) 75 Maximum Arm Length (mm) 750 Maximum Blade Length (mm) 750 Product Width (mm) 150 Product Depth (mm) 240 Product Height (mm) 90
Brand: Exalto Wiper Technologies B.V. (Article code: XA2167.40-65) (Barcode: 8720763542440)
-
