SKU:
CN FPT-N60-270
1-2 weeks delivery time
Our managers will contact you and clarify the terms of the order
The FPT Marine Diesel Engine Type N60-270 is a robust six-cylinder engine offering 270 horsepower for maritime applications. With a turbocharged fuel system and a heat exchanger cooling system, this engine is built for efficiency and reliability in tough marine conditions, complying with global emission standards.
- Description
- Ask a Question
-
FPT Marine Diesel Engine Type N60-270
The FPT Marine Diesel Engine Type N60-270 offers robust and efficient performance for maritime applications. Below are the key specifications and features:
- Engine Type: 4-stroke diesel engine
- Configuration: Inline 6 cylinders
- Displacement: 5.9 liters (5880 cc)
- Bore x Stroke: 102 mm x 120 mm
- Aspiration: Turbocharged with aftercooler
Performance
This engine delivers exceptional power and torque suitable for a variety of marine tasks.
- Maximum Power: 270 hp (201 kW) @ 2800 RPM
- Continuous Power: 230 hp (169 kW) @ 2700 RPM
- Torque: 881 Nm @ 1400 RPM
Fuel System
Designed for efficiency, the FPT engine operates with a fuel system that ensures both performance and cost-effectiveness.
- Fuel Type: Diesel
- Fuel Injection System: Common rail direct injection
- Fuel Consumption: Specific consumption varies with operational conditions, but it generally remains efficient compared to similar engines.
Dimensions and Weight
The compact design of the engine allows for easy installation without sacrificing performance.
- Length: Approximately 1281 mm
- Width: Approximately 710 mm
- Height: Approximately 990 mm
- Dry Weight: Approximately 630 kg
Cooling System
To ensure optimal performance in maritime environments, the engine uses an advanced cooling system.
- Cooling Type: Heat exchanger with seawater cooling
Emission Standards
The FPT engine complies with global emission standards to minimize environmental impact.
- Compliance: IMO Tier II, EU Stage IIIA, EPA Tier 3
-
