SKU:
ALP 9064707
€ 4.520,19
1-2 weeks delivery time
-
+
The NHK MEC KE-7+ Throttle Control System for a single engine and two steering stations provides advanced electronic throttle control with robust configuration options such as CANbus and power harnesses, push-pull cables, idle switches, fuses, and alarms. It supports 9V to 32V DC, has a max actuator current of 16A, and throttle travel up to 80mm, with article number 9064707.
- Description
- Ask a Question
-
NHK MEC KE-7+ Throttle Control System Single Engine/2 Steering Stations
Advanced electronic throttle control solution designed for single engine configurations with dual steering stations. Engineered for reliability and smooth operation across a wide range of marine environments.
- NHK MEC Canbus T-Harness (R/C-1) (NM0647-09) — Code: 9064761
- NHK MEC KE-6+/7+ Shift / Throttle Actuator (NM0199-00) — Code: 9064749
- NHK MEC KE+ CANbus T-Harness (R/C) (NM0647-10) — Code: 9064762
- NHK MEC KE+ Dual Action Top Mount Control, Inboard Style (SST), Chrome (lever on left side) (NM1003-00) — Code: 9064751
- NHK MEC KE-6+/7+ Control Unit, 12V/24V (NM2447-00) — Code: 9064882
- Seastar Control Cable 'Xtreme' CCX633 6' (1.83m) for Inboard-, Stern Drive- & Outboard Engines — Code: CCX63306
- NHK MEC KE Power Harness 5m (NM0414-28) — Code: 9064830
- NHK MEC CANbus T-Harness (single engine) (NM0647-11) — Code: 9064763
- NHK MEC KE+ CANbus harness 8m (NM0649-08) — Code: 9064778
- NHK MEC KE-6+/7+ Actuator Harness, 2m (NM0667-00) — Code: 9064975
- NHK MEC KE-5+ Harness Shift, 5m (NM0640-05) — Code: 9064955
- Supply Voltage: 9V ~ 32V DC
- Current Consumption: 0.5A Stand By or less
- Starting Current Actuator: 16A Max, 5A typical, 49N (5 kgf) load
- Temperature Environment: -20°C / +77°C (-4°F / 170°F)
- Throttle Travel: Max. 80mm
- Shift Output: Max. 8A contact point capacity (normally open)
- Article number: 9064707
- Optional or configurable components include: CANbus harness, Power harness, Push-pull cable, Idle switch, Idle switch extension harness, Automatic fuse, Acoustic alarm.
-
