SKU:
ALP 9064708
€ 6.772,25
1-2 weeks delivery time
-
+
The NHK MEC KE-7+ Throttle Control System for dual engines and a single steering station is designed for reliable, precise marine throttle control with optional CANbus and power harnesses, push-pull cables, and alarm components. It supports 9V to 32V DC, 16A max actuator current, and 80mm throttle travel, with article number 9064708.
- Description
- Ask a Question
-
NHK MEC KE-7+ Throttle Control System Dual Engine/1 Steering Station
The NHK MEC KE-7+ is a robust throttle control system designed for dual engine setups with a single steering station. Engineered for performance and precision, it supports seamless control and integration across various marine applications. This system is compatible with optional accessories including a CANbus harness, power harness, push-pull cable, idle switch, idle switch extension harness, automatic fuse, and an acoustic alarm, allowing for flexible configuration.
- NHK MEC KE-4+ Canbus T-Harness (Port) (NM0647-12)
Code: 9064764 - NHK MEC KE-5+ Harness Shift, 5m (NM0640-05)
Code: 9064955 - Nhk Mec Ke-6+/7+ Shift / Throttle Actuator (NM0199-00)
Code: 9064749 - NHK MEC KE Power Harness 5m (NM0414-28)
Code: 9064830 - Nhk Mec Ke-6+/7+ Actuator Harness, 2m (NM0667-00)
Code: 9064975 - NHK MEC KE+ CANbus harness 8m (NM0649-08)
Code: 9064778 - NHK MEC Canbus T-Harness (R/C-1) (NM0647-09)
Code: 9064761 - Nhk Mec Ke-6+/7+ Control Unit, 12V/24V (NM2447-00)
Code: 9064882 - Seastar Control Cable 'Xtreme' CCX633 6' (1.83m), suitable for inboard-, sterndrive-, and outboard engines
Code: CCX63306 - Nhk Mec Ke-4+ Dual Action Twin Top Mount Control, Inboard Style (SST), Chrome (NM1053-00)
Code: 9064756 - NHK MEC KE-4+ Canbus T-Harness (Starboard) (NM0647-13)
Code: 9064765
- Control
- Supply Voltage: 9V ~ 32V DC
- Current Consumption: 0.5A Stand By or less
- Starting Current Actuator: 16A Max, 5A typical, 49N (5 kgf) load
- Temperature Environment: -20°C / +77°C (-4°F / 170°F)
- Throttle Travel: Max. 80mm
- Shift Output: Max. 8A contact point capacity (normally open)
- General
- Article number: 9064708
- NHK MEC KE-4+ Canbus T-Harness (Port) (NM0647-12)
-
