SKU:
ALP 9064701
€ 3.636,86
1-2 weeks delivery time
-
+
The NHK MEC KE-6+ throttle control system for single engine configurations with one steering station provides efficient and responsive electronic throttle control with a modular design that supports optional components. It shares similar technical specifications such as supply voltage, current consumption, and throttle output formats. The package includes necessary harnesses, control units, actuators, and cables, with options for additional components like CANbus harness, power harness, push-pull cable, and alarms.
- Description
- Ask a Question
-
NHK MEC KE-6+ Throttle Control System Single Engine/1 Steering Station
Developed for single engine setups with one steering station, the NHK MEC KE-6+ system ensures efficient and responsive electronic throttle control. Its modular configuration allows for optional components to be added, making it adaptable to various marine installations.
- Supply Voltage: 9V ~ 32V DC
- Current Consumption: 0.5A Stand By or less
- Starting Current Actuator: 16A Max, 5A typical, 49N (5 kgf) belasting
- Shift Travel: 26-30-34-40mm
- Temperature Environment: -20°C / +77°C (-4°F / 170°F)
- Throttle Travel: Max. 80mm
- Throttle Output:
- Current: 3mA to 21mA
- Analog Voltage: 0.2V to 4.53V
- PWM: 6% to 94% Duty Cycle, 500Hz
- CAN: SAE J1939: 250kbits/s
- Article Number: 9064701
Included in this package:
- NHK MEC CANbus T-Harness (Single Engine) (NM0647-11) – Code: 9064763
- NHK MEC KE+ Dual Action Top Mount Control, Inboard Style (SST), Chrome (Lever on Left Side) (NM1003-00) – Code: 9064751
- NHK MEC KE-5+ Harness, Throttle 5m (NM0666-05) – Code: 9064973
- NHK MEC KE-6+/7+ Control Unit, 12V/24V (NM2447-00) – Code: 9064882
- NHK MEC Canbus T-Harness (R/C-1) (NM0647-09) – Code: 9064761
- NHK MEC KE-6+/7+ Shift / Throttle Actuator (NM0199-00) – Code: 9064749
- NHK MEC KE-6+/7+ Actuator Harness, 2m (NM0667-00) – Code: 9064975
- NHK MEC KE+ CANbus Harness 8m (NM0649-08) – Code: 9064778
- Seastar Control Cable 'Xtreme' CCX633 6' (1.83m) for Inboard-, Stern Drive- & Outboard Engines – Code: CCX63306
- NHK MEC KE Power Harness 5m (NM0414-28) – Code: 9064830
Optional or configurable components include: CANbus harness, power harness, push-pull cable, idle switch, idle switch extension harness, automatic fuse, and acoustic alarm.
-
