SKU:
MM 004556
€ 208,63
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The H8 Fixed Thimble Halyard Shackle is a versatile, high-performance shackle designed for demanding applications. Made from machined 6061 aluminum, it includes a captive stainless steel cross pin and a recessed thread for a full throat opening. The 2:1 split design allows for easy installation and removal, with a working load limit of 1810 kg and a breaking load of 3630 kg.
- Description
- Ask a Question
-
H8 Fixed Thimble Halyard Shackle
The H8 Fixed Thimble Halyard Shackle is a high-performance shackle designed for more demanding applications. It features a split 2:1 model for easy installation and removal, making it an ideal choice for halyard systems.
- Captive Pin: Stainless steel cross pin
- Material: Machined 6061 aluminum
- Thread Design: Recessed thread allows for full throat opening
- Coating: Hard-coat anodized for maximum coating durability
- Options: Available with a fixed thimble or a 2:1 sheave
- Special Feature: Split 2:1 model opens like a snatch block for easy installation and removal
- Dimensions:
- A: 21.2 mm
- B: 14.3 mm
- C: 80.2 mm
- D: 33.5 mm
- E: 19.3 mm
- F: 8.1 mm
- Max Line Size: 12 mm
- Weight: 87 g
- Working Load Limit: 1810 KG
- Breaking Load: 3630 KG
Product number: TY1408
Brand: Tylaska
-
