Ronstan RF7 Swiveling Mainsheet Cleat Base

SKU: MM 050121

€ 173,32

1-2 weeks delivery time
Price incl. 19% VAT

- +

Add to cart

The Swiveling Mainsheet Cleat Base includes a medium C-Cleat™ and a 5mm pin, with an adjustable cleating arm for optimal control. It features twin ball bearings to minimize friction and a ratchet system to prevent the arm from falling, supporting a maximum load of 215kg.

Description
Ask a Question

Swiveling Mainsheet Cleat Base

This ball bearing swivelling cleat base includes a medium C-Cleat™ and a 5mm (3/16") pin. The height and angle of the cleating arm are adjustable for optimum control. The twin ball bearing race minimizes friction, while the adjustable ratchet system prevents the arm from falling to leeward. The cleat arm is supported by twin rows of ball bearings, and stops are provided to limit rotation to 260°. The cleat arm cradle part's rotation stop can be cut off to allow full 360° rotation. The swivel fork features a 5mm and 11.8mm (9/16") gap for low-profile attachment to the head post of a block.
- Adjustable ratchet system to prevent arm from falling to leeward.
- Supports cleat arm with twin rows of ball bearings.
- Rotation stop can be cut off for full 360° rotation.
- Load ratings are based on a 120° change in line direction.
- Line load should be limited to 175kg (385lb).
Specifications
- Breaking Load (B.L.): 430kg
- Maximum Working Load (M.W.L.): 215kg
- Weight: 342g
- Rope Diameter Ø: 3 - 12mm
- Product Number: RF7
- Brand: Ronstan
