Ronstan RF48210 Series 40 Ball Bearing Orbit Block, Double, Becket

SKU: MM 051326

€ 86,73

1-2 weeks delivery time
Price incl. 19% VAT

- +

Add to cart

The Series 40 Ball Bearing Orbit Block™, Double, Becket is a double sheave block with a swivel shackle and removable becket pin for flexible line setup. It’s suited for small craft rigging, supporting a working load of 600 kg, breaking load of 1200 kg, and weighs 130 g.

Description
Ask a Question

Series 40 Ball Bearing Orbit Block™, Double, Becket

This double sheave block includes a swivel shackle head and integrated becket for flexible rigging setups. Designed for compact, high-load handling on small sailing craft.
- 2-stage ball bearing system for reduced friction and smooth operation
- Swivel headposts can rotate freely or be fixed at 0° or 90° positions
- Becket pin is removable for easy line splicing, secured with a split ring
- Ideal for mainsheet and spinnaker systems on dinghies, catamarans, and sportsboats up to 8m (26ft)
- Suitable for halyards, vangs, and backstays on boats up to 8m (26ft)
- Can be used for control lines on larger yachts
- Sheave and ball bearings made of high-strength acetal
- Frame and cheeks made of toughened, glass fibre reinforced nylon
- Head fittings and hubs made from grade 316 stainless steel
- Block type: Double
- Breaking load (B.L.): 1200 kg
- Maximum working load (M.W.L.): 600 kg
- Maximum rope diameter: 10 mm
- Weight: 130 g
- Pin diameter: 5 mm
- Becket M.W.L.: 400 kg, B.L.: 800 kg
- Product number: RF48210
- Brand: Ronstan
