Rule RM800B-24 - Rule-Mate 800 Submersible Pump 24V

Rule RM800B-24 - Rule-Mate 800 Submersible Pump 24V

The Rule RM800B-24 Rule-Mate 800 Submersible Pump is a high-performance bilge pump designed for efficient water removal in smaller vessels. Powered by 24V DC, this pump provides an impressive output of up to 56 liters per minute (12 gallons/minute), ensuring quick and reliable water evacuation. It features an automatic operation with an integral sensor that activates the pump when water levels rise. In case of a fouled sensor, the pump automatically switches to a 2.5-minute cycle mode to prevent dry running. The Rule RM800B-24 is ideal for marine environments, with a robust plastic body, backflow prevention, and air vents to prevent airlocks in installations. With a low amp draw, this pump helps conserve battery power while maintaining high performance. The compact and durable design makes it perfect for installation in tight spaces, and the quick-release inlet strainer allows for easy maintenance and cleaning. Ignition-protected for added safety, this pump is an essential tool for keeping your bilge dry and ensuring your boat operates smoothly.

Key Features:

• Fully automated bilge pump with integral sensor and fail-safe backup mode
• Output of up to 56 liters/minute (12 gallons/minute) for efficient water removal
• Compact and durable design suitable for smaller vessels
• Quick-release inlet strainer for easy cleaning and maintenance
• Backflow prevention to minimize water left behind in the bilge
• Air vents to prevent air locks in challenging installations
• Low amp draw helps conserve battery power
• Ignition protected for safe use in marine environments
• Automatic operation with sensor-based activation and backup mode
• Compact and lightweight, suitable for tight spaces on smaller boats

Specifications:

• Brand: Rule
• Model Number: RM800B-24
• Power Supply: 24V DC
• Connections: For 19mm (3/4") bore hose on outlet
• Dimensions: 112mm high x 130mm long x 73mm wide
• Fuse Size: 4 amps
• Output: Up to 56 liters/minute (12 gallons/minute)
• Maximum Recommended Discharge Head: 3 meters
• Material: Tough plastic body
• Weight: 0.48 kg (approx. 0.68 kg packed)
• Packaged Dimensions: 18.00 x 8.00 x 20.00 cm
• Low Amp Draw: Energy-efficient for extended battery life
• Backflow Prevention: Reduces water retention in the bilge
• Air Vents: Prevents air locks during installation
• Easy to Maintain: Quick-release strainer for hassle-free cleaning
• Ignition Protected: Safe for use in marine environments
• Intermittent Duty Rating: Designed for continuous use in bilge pumping
• Motor Life: Approximately 1500 hours of operation

Application:

The Rule RM800B-24 Rule-Mate 800 Submersible Pump is designed for use in small to medium-sized vessels, including yachts, motorboats, and cruisers. It is ideal for automatic bilge pumping and water transfer, ensuring that your vessel stays dry and free of excess water. Suitable for both freshwater and saltwater environments, it provides reliable performance for a range of applications, including deck showers, water transfer, and deck wash. The pump is perfect for both new installations and replacements, offering quick and easy integration into existing systems.

Benefits:

• Reliable and automatic bilge pumping with integral sensor for hands-free operation
• Compact design for easy installation in tight spaces
• Efficient water removal with a high output of 56 liters/minute (12 gallons/minute)
• Energy-efficient, low amp draw conserves battery life
• Quick-release inlet strainer allows for simple maintenance and cleaning
• Backflow prevention ensures minimal water retention in the bilge
• Ignition-protected and safe for use in marine environments
• Designed for intermittent duty with extended motor life
