Rule RM500B-24 - Rule-Mate 500 Submersible Pump 24V

Rule-Mate 500 Submersible Pump 24V

The Rule-Mate 500 Submersible Pump 24V is designed for smaller vessels, offering an efficient and reliable solution for keeping your bilge dry. This compact yet powerful pump delivers up to 31 litres per minute (7 gallons per minute) with a maximum recommended discharge head of 2 meters. Ideal for boats and marine applications, the Rule-Mate 500 features an integral sensor for fully automated operation. With a built-in backup feature to prevent dry running, the pump reverts to a 2.5-minute cycle mode in case of sensor malfunctions. This pump includes a backflow prevention mechanism to minimize water left behind in the bilge, along with air vents to prevent air locks. A quick-release inlet strainer makes maintenance hassle-free. The low amp draw ensures battery conservation, while the ignition protection and thermal cut-off enhance safety during operation. Whether you need to transfer water, keep your bilge clean, or ensure proper drainage, this pump is designed to perform efficiently.

Key Features:

• Fully automated bilge pump with integral sensor for efficient operation
• Backup feature prevents dry running by switching to 2.5-minute cycle mode if sensor is fouled
• Output of up to 31 litres/minute (7 gallons/minute) with max. discharge head of 2 meters
• Compact design ideal for smaller vessels and tight spaces
• Backflow prevention reduces water accumulation in the bilge, improving performance
• Air vents prevent air locks in challenging installations, ensuring continuous flow
• Quick-release inlet strainer for easy cleaning and maintenance
• Low amp draw for energy efficiency, conserving battery life
• Ignition protected and equipped with thermal cut-off for added safety
• Designed for freshwater and saltwater applications, ensuring versatile use

Specifications:

• Voltage: 24V DC
• Dimensions: 112mm high, 130mm long, 73mm wide
• Fuse Size: 2 amps
• Maximum Current: 2.8 amps
• Output: Up to 31 litres/minute (7 gallons/minute)
• Max. Recommended Discharge Head: 2 meters
• Connections: For 19mm (3/4") bore hose on outlet
• Material: High-strength plastic body for durability in marine environments
• Backup Feature: Yes, prevents dry running by switching to a 2.5-minute cycle mode
• Air Vents: Yes, prevents air locks for smooth operation
• Quick-release Inlet Strainer: Yes, simplifies cleaning and maintenance
• Ignition Protection: Yes
• Thermal Cut-off: Built-in for overheat protection
• Water Type Compatibility: Suitable for both fresh and saltwater applications
• Packaged Dimensions: L: 18.00 x H: 9.00 x W: 20.00 cm
• Actual Weight: 0.46 kg (Approx. 0.66 kg packed)

Benefits:

• Automated operation ensures the bilge remains dry with minimal manual intervention
• Low power consumption and battery conservation for extended operation time
• Compact size fits perfectly in tight spaces, ideal for smaller vessels and boats
• Corrosion-resistant, high-strength plastic body for reliability and longevity in marine environments
• Quick-release strainer design makes cleaning hassle-free and efficient
• Improved safety with ignition protection and thermal cut-off feature
• Easy installation and maintenance, perfect for DIY boat owners
