Johnson Pump 10-24800-01 - 'Viking' Compact Manual Bilge Pump, Built-In For Mounting, 45l/Min, Ø25 Of 38mm

SKU: ALP 66102480001

€ 97,15

1-2 weeks delivery time

- +

Add to cart

The Johnson Pump 'Viking' Compact Manual Bilge Pump is designed for easy bulkhead installation with a self-sealing fit, offering flow rates up to 45L/min. It features durable materials and a rattle-free design for reliable, low-maintenance operation.

Description
Ask a Question

Johnson Pump 'Viking' Compact Manual Bilge Pump, Built-In For Mounting, 45l/Min, Ø25 Or 38mm

The Viking Compact pump is designed for quick installation from one side of the bulkhead using only four screws. It features a durable, watertight gasket for a self-sealing fit, with the pump body recessed behind the bulkhead so only the handle shows in the cabin or cockpit. The pump offers versatile hose connections with 360° swivel ports available in Ø25mm and Ø38mm sizes, including standard KlickTite connectors for easy hose attachment.
- Limited 3 Year Warranty
- Flow rate: 34.5 L/min (9.1 US GPM) with Ø25mm connections; 45 L/min (11.9 US GPM) with Ø38mm connections
- Quick installation from one side of the bulkhead
- Fits industry standard aperture, suitable for tight spaces
- Robust combined pump handle and cover
- Self-priming for immediate pumping action
- Maximum lift/head: 3.3 m (10'8")
- Low maintenance, cost-effective, and infrequent servicing required
- Durable gasket ensures tight bulkhead fit
- Rattle-free design
- Polypropylene pump body
- All metal parts made of stainless steel
- Easy single diaphragm pump action
- KlickTite standard connectors for ports
- Swivel hose connectors
- Heavy duty non-choke valves throughout
- High flow tricuspid valve on outlet port
- Complies with ISO 15083 standard
Properties:
- Article number: 66102480001
- Model: Viking, Built-In for Mounting
- Connection sizes: 25 & 38mm
- Capacity: 45l/min
