Johnson Pump 10-24727-02 - Self-Priming Impeller Pump F38B-19, 24V, 35 l/min, Connection 1" Hose & 1/2" BSP

SKU: ALP 66102472702

€ 306,79

1-2 weeks delivery time

- +

Add to cart

The Johnson Pump 10-24727-02 is a 24V self-priming impeller pump designed for heavy-duty applications. It provides a flow rate of 35 l/min and features a bronze body, oil-resistant nitrile impeller, and continuous operation capabilities. This model is ideal for bilge, deck wash, fire, and circulating pumps, with a self-priming ability up to 3 meters, ensuring reliable performance even under tough conditions.

Description
Ask a Question

Johnson Pump 10-24727-02 - Self-Priming Impeller Pump F38B-19, 24V, 35 l/min, Connection 1" Hose & 1/2" BSP

Built to perform under tough conditions, this self-priming impeller pump is ideal for various applications, including bilge pumps, deck wash pumps, fire pumps, circulating pumps, and refuelling pumps for oil and diesel. The heavy-duty motor ensures longevity and reliable performance.
- Motor: Heavy-duty motor with built-in thermal overload for added protection.
- Operation: Continuous operation capable up to a maximum 0.6 bar head pressure.
- Self-priming: Self-priming up to 3 m under perfect conditions; maximum head should not exceed 6 m.
- Flow Rate: Output up to 35 litres/minute at free flow; approx. 31 l/m at 3m head.
- Material: Brass pump head and oil-resistant nitrile impeller.
- Shaft Seal: Lip seal ensures durability.
- Connections: 1" hose inner diameter directly to inlet/outlet connection or via R1/2" female thread for corresponding fittings (not included).
- Amperage: 7.1A; fuse size 10A.
- Dimensions: Height: 9.0 cm, Width: 12 cm, Length: 17.5 cm.
- Weight: 3 kg.
- Voltage: 24V.
- Model: F38B-19.
- Capacity: 35 l/min.
- Seal: Lip Seal.
- Body: Bronze.
- Article Number: 66102472702.
- EAN Number: 8719182062448.
