SKU:
ALP TMC260247
€ 1.945,47
1-2 weeks delivery time
-
+
The TMC260 gearbox with a 2.47:1 gear ratio in both forward and reverse modes offers balanced marine performance for pleasure and light commercial use, supporting a max input torque of 210Nm (pleasure) and 140Nm (commercial), with a dry weight of 18kg and oil quantity of 1.2 liters of ATF. Its article number is TMC260247 and EAN 8719182622420.
- Description
- Ask a Question
-
Technodrive Mechanical Marine Gearbox TMC260, R=2,47:1
The TMC260 gearbox with a 2.47:1 gear ratio in both forward and reverse modes is engineered for balanced marine performance. Ideal for setups requiring uniform directional power transfer, it is compatible with pleasure and light commercial applications.
- Article number: TMC260247
- EAN number: 8719182622420
- Forward Ratio: R=2.47:1
- Reverse Ratio: R=2.47:1
- Max. input torque, pleasure: 210Nm
- Max. input torque, commercial: 140Nm
- Max. input power, pleasure: 84kW
- Max. input power, commercial: 61kW
- Max. input power: 5000 rpm
- Dry weight: 18kg
- Oil quantity: 1,2l
- Oil type: ATF
-
