SKU:
ALP TM93A209
€ 3.899,37
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM93A, featuring a 2.09:1 forward and reverse ratio, is designed for high torque in both pleasure and commercial marine applications. It provides a max torque of 40 kgm for pleasure use and 31 kgm for commercial use. With a dry weight of 51 kg, it uses 2 liters of oil and operates at 24 bar pressure.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM93A, R=2,09:1
The Technodrive Hydraulic Marine Gearbox TM93A with a forward and reverse ratio of R=2,09:1 offers strong torque for a wide range of marine applications, with a durable design tailored for both pleasure and commercial use.
- Article Number: TM93A209
- EAN Number: 8719182621768
- Forward Ratio: R=2.09:1
- Reverse Ratio: R=2.09:1
- Max Input Power: 4500 rpm
- Dry Weight: 51kg
- Oil Quantity: 2l
- Down Angle Output Shaft: 8°
- Lubricating Pressure: 0.5-1.5 bar
- Operating Pressure: 24 bar
- Max Torque (Pleasure Use): 40 kgm
- Max Torque (Commercial Use): 31 kgm
-
