SKU:
ALP TM93A151
€ 3.899,37
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM93A, with a 1.51:1 forward and reverse ratio, provides optimal performance for a wide range of vessels. It delivers a max torque of 48 kgm for pleasure and 37 kgm for commercial use. The gearbox requires 2 liters of oil and operates under 24 bar pressure, offering a reliable and efficient solution.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM93A, R=1,51:1
The Technodrive Hydraulic Marine Gearbox TM93A with a forward and reverse ratio of R=1,51:1 is designed for a variety of marine vessels, delivering optimal performance and torque for both recreational and commercial uses.
- Article Number: TM93A151
- EAN Number: 8719182621768
- Forward Ratio: R=1.51:1
- Reverse Ratio: R=1.51:1
- Max Input Power: 4500 rpm
- Dry Weight: 51kg
- Oil Quantity: 2l
- Down Angle Output Shaft: 8°
- Lubricating Pressure: 0.5-1.5 bar
- Operating Pressure: 24 bar
- Max Torque (Pleasure Use): 48 kgm
- Max Torque (Commercial Use): 37 kgm
-
